Ducati Monster S2R 1000 - 2007 Specifications and Reviews
2007
General information | |
Category | Naked bike |
Year | 2007 |
Model | Ducati Monster S2R 1000 |
| |
Engine and Transmission Specifications | |
Exhaust system | 2 aluminium mufflers |
Clutch | Dry multiplate with hydraulic control |
Transmission type,final drive | Chain |
Gearbox | 6-speed |
Cooling system | Air |
Fuel control | Desmodromic valve control |
Fuel system | Injection. Marelli electronic fuel injection, 45 mm throttle body |
Valves per cylinder | 2 |
Bore x stroke | 94.0 x 71.5 mm (3.7 x 2.8 inches) |
Compression | 10.0:1 |
Torque | 94.10 Nm (9.6 kgf-m or 69.4 ft.lbs) @ 9600 |
Power | 93.87 |
Engine type | V2, four-stroke |
Capacity: | 992.00 ccm (60.53 cubic inches) |
| |
Brakes, suspension, Frame and wheels | |
Rear brakes diameter | 245 mm (9.6 inches) |
Rear brakes | Single disc |
Front brakes diameter | 320 mm (12.6 inches) |
Front brakes | Double disc |
Rear tyre dimensions | 180/55-ZR17 |
Front tyre dimensions | 120/70-ZR17 |
Rear suspension travel | 148 mm (5.8 inches) |
Rear suspension | Progressive linkage with preload and rebound adjustable Sachs monoshock. Aluminium single-sided swingarm |
Front suspension travel | 130 mm (5.1 inches) |
Front suspension | Showa 43 mm fully adjustable upside-down fork |
Rake (fork angle) | 24.0° |
Frame type | Tubular steel trellis frame |
Physical measures and capacities | |
Fuel capacity | 14.00 litres (3.70 gallons) |
Wheelbase | 1,440 mm (56.7 inches) |
Seat height | 800 mm (31.5 inches) If adjustable, lowest setting. |
Power/weight ratio | 0.5274 HP/kg |
Dry weight | 178.0 kg (392.4 pounds) |
Other specs | |
Color options | (red with white stripe - red - black) (black with white stripe - matte black - black) (silver with black stripe - matte black - black), |
