Ducati Scrambler Icon - 2024 Specifications and Reviews
General information | |
| Category | Naked bike |
| Model year | 2024 |
| Model name | Ducati Streetfighter V2 |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Lightweight 2-1-2-1 system with catalytic converter and two lambda probes. |
| Emission details | Euro 5 |
| Greenhouse gases | 139.2 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel consumption | 6.00 litres/100 km (16.7 km/l or 39.20 mpg) |
| Clutch | Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder |
| Transmission type | Chain (final drive) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Fuel control | Desmodromic valve control |
| Fuel system | Injection. Eelectronic fuel injection, twin injectors, elliptical throttle bodies |
| Valves per cylinder | 4 |
| Bore x stroke | 100.0 x 60.8 mm (3.9 x 2.4 inches) |
| Compression | 12.5:1 |
| Torque | 101.4 Nm (10.3 kgf-m or 74.8 ft.lbs) @ 9000 RPM |
| Power output | 152.9 HP (111.6 kW)) @ 10750 RPM |
| Engine type | V2, four-stroke |
| Capacity: | 955.0 ccm (58.27 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Seat | Dual seat |
| Wheels | 5-spokes light alloy. Pirelli Diablo Rosso IV tyres. |
| Rear brakes | Single disc. Two-piston calipers. ABS. |
| Diameter | 330 mm (13.0 inches) |
| Front brakes | Double disc. Floating discs. Four-piston calipers. Radially mounted. ABS. |
| Rear tire | 180/60-ZR17 |
| Front tire | 120/70-ZR17 |
| Rear wheel travel | 130 mm (5.1 inches) |
| Rear suspension | Fully adjustable Sachs unit. Aluminum single-sided swingarm. |
| Front wheel travel | 120 mm (4.7 inches) |
| Front suspension | Fully adjustable Showa BPF fork. 43 mm chromed inner tubes |
| Trail | 94 mm (3.7 inches) |
| Rake (fork angle) | 24.0° |
| Frame type | Monocque aluminium |
Physical measures and capacities | |
| Fuel capacity | 17.00 litres (4.49 US gallons) |
| Wheelbase | 1465 mm (57.7 inches) |
| Seat height | 845 mm (33.3 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.8589 HP/kg |
| Weight incl. oil, gas, etc | 200.0 kg (440.9 pounds) |
| Dry weight | 178.0 kg (392.4 pounds) |
Other specs | |
| Comments | Riding Modes, Power Modes, Ducati Traction Control, Wheelie Control. |
| Factory warranty | 2 years unlimited mileage |
| Light | LED lights |
| Instruments | TFT colour display |
| Starter | Electric |
| Color options | Ducati Red, Storm Green |
