Yamaha XVZ13TFL MM Limited - 2000 Specifications and Reviews

2000
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryTouring
Year2000
ModelYamaha XVZ13TFL MM Limited



Engine and Transmission Specifications

Exhaust system4 into 2
Greenhouse gases136.4 CO
Fuel consumption5.88 litres/100 km (17.0 km/l or 40.00 mpg)
ClutchWet, multiple-disc
Transmission type,final driveShaft drive (cardan)
Gearbox5-speed
Cooling systemLiquid
Lubrication systemWet Sump
IgnitionDigital TCI
Fuel controlDOHC
Fuel systemCarburettor. Mikuni 32mm /4
Valves per cylinder4
Bore x stroke79.0 x 66.0 mm (3.1 x 2.6 inches)
Compression10.0:1
Top speed193.1 km/h (120.0 mph)
Power98.00
Engine typeV4, four-stroke
Capacity:1294.00 ccm (78.96 cubic inches)



Brakes, suspension, Frame and wheels

Rear brakes diameter320 mm (12.6 inches)
Rear brakesSingle disc. 4 Piston Caliper
Front brakes diameter298 mm (11.7 inches)
Front brakesDouble disc. 2 Piston Calipers
Rear tyre dimensions150/90-15
Front tyre dimensions150/80-16
Rear suspension travel105 mm (4.1 inches)
Rear suspensionMonoshock, air adjustable 0 to 57psi
Front suspension travel140 mm (5.5 inches)
Front suspensionAir adjustable 0 to 7.1psi
Trail152 mm (6.0 inches)
Rake (fork angle)29.1°
Frame typeDouble Cradle with solid mounted engine used as frame member.

Physical measures and capacities

Reserve fuel capacity3.50 litres (0.92 gallons)
Fuel capacity22.50 litres (5.94 gallons)
Wheelbase1,705 mm (67.1 inches)
Ground clearance155 mm (6.1 inches)
Overall width900 mm (35.4 inches)
Overall length2,655 mm (104.5 inches)
Overall height1,565 mm (61.6 inches)
Seat height750 mm (29.5 inches) If adjustable, lowest setting.
Power/weight ratio0.2678 HP/kg
Weight incl. oil, gas, etc394.0 kg (868.6 pounds)
Dry weight366.0 kg (806.9 pounds)

Other specs

Color optionsPearl White / Ivory two-tone with tan seats
StarterElectric
