Yamaha Royal Star Venture S - 2011 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2011 |
| Model | Yamaha Royal Star Venture S |
| | |
Engine and Transmission Specifications | |
| Greenhouse gases | 129.9 CO |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Transmission type,final drive | Shaft drive (cardan) |
| Gearbox | 5-speed |
| Cooling system | Liquid |
| Ignition | TCI: Transistor Controlled Ignition |
| Fuel control | DOHC |
| Fuel system | Carburettor. (4) 32mm Mikuni CV |
| Valves per cylinder | 4 |
| Bore x stroke | 79.0 x 66.0 mm (3.1 x 2.6 inches) |
| Compression | 10.0:1 |
| Torque | 120.68 Nm (12.3 kgf-m or 89.0 ft.lbs) @ 4750 |
| Power | 97.00 |
| Engine details | Single-axis internal counterbalancer reduces engine vibration. |
| Engine type | V4, four-stroke |
| Capacity: | 1294.66 ccm (79.00 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | 7-spoke cast |
| Rear brakes diameter | 320 mm (12.6 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 298 mm (11.7 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 150/90-15 |
| Front tyre dimensions | 150/80-16 |
| Rear suspension travel | 104 mm (4.1 inches) |
| Rear suspension | Single shock |
| Front suspension travel | 140 mm (5.5 inches) |
| Front suspension | Telescopic fork |
Physical measures and capacities | |
| Fuel capacity | 22.71 litres (6.00 gallons) |
| Wheelbase | 1,704 mm (67.1 inches) |
| Overall width | 899 mm (35.4 inches) |
| Overall length | 2,654 mm (104.5 inches) |
| Overall height | 1,565 mm (61.6 inches) |
| Seat height | 749 mm (29.5 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 394.2 kg (869.0 pounds) |
Other specs | |
| Light | None |
| Starter | Electric & kick |
| Ground clearance | 99 mm (3.9 inches) |
| Rear tyre | 18/9-Ma8 |
| Front tyre | 18/7-Ma8 |
| Rear wheel travel | 127 mm (5.0 inches) |
| Rear Suspension | Swingarm |
| Front wheel travel | 127 mm (5.0 inches) |
| Front Suspension | Independent double wishbone |
| Valves per cylinder | 2 |
| Bore x Stroke | 47.0 x 51.0 mm (1.9 x 2.0 inches) |
| Compression | 10.2:1 |
| Model | Yamaha Raptor 90 |
| Color options | Impact Blue/Deep Blue |
| Factory warranty | 5 Year (Limited Factory Warranty) |
| Carrying capacity | 15-gallon trunk and a pair of color-matched 9.3-gallon sidebags |
| Seat | Ergonomically designed bucket-type seats with plush, wraparound passenger backrest |
