Triumph Sprint GT - 2011 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2011 |
| Model | Triumph Sprint GT |
Engine and Transmission Specifications | |
| Driveline | X ring chain. Primary drive: Gear. |
| Clutch | Wet. multi-plate |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Ignition | Digital-inductive type vis engine management system |
| Fuel control | DOHC |
| Fuel system | Injection. Multipoint sequential electronic fuel injection with SAI |
| Bore x stroke | 79.0 x 71.4 mm (3.1 x 2.8 inches) |
| Compression | 12.0:1 |
| Torque | 108.48 Nm (11.1 kgf-m or 80.0 ft.lbs) @ 6300 |
| Power | 128.00 |
| Engine type | In-line three, four-stroke |
| Capacity: | 1050.00 ccm (64.07 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 255 mm (10.0 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 320 mm (12.6 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 180/55-ZR17 |
| Front tyre dimensions | 150/80-R16 |
| Rear suspension | Showa monoshock with adjustable preload and rebound damping. 152mm rear wheel travel |
| Front suspension | Showa 43mm cartridge forks with dual rate springs and adjustable preload. 127mm travel |
| Rake (fork angle) | 23.5° |
| Frame type | Aluminum beam perimeter |
| | |
Physical measures and capacities | |
| Fuel capacity | 20.06 litres (5.30 gallons) |
| Wheelbase | 1,537 mm (60.5 inches) |
| Overall width | 759 mm (29.9 inches) |
| Overall length | 2,250 mm (88.6 inches) |
| Overall height | 1,209 mm (47.6 inches) |
| Seat height | 815 mm (32.1 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 267.6 kg (590.0 pounds) |
Other specs | |
| Comments | Sold in Germany |
| Dry weight | 226.0 kg (498.2 pounds) |
| Wheels | Street tyres |
| Rear tyre | 225/40-10 |
| Front tyre | 165/70-10 |
| Rear Suspension | Alu swing arm |
| Front Suspension | Double A-arm |
| Transmission type,final drive | Chain |
| Valves per cylinder | 4 |
| Bore x Stroke | 96.0 x 65.2 mm (3.8 x 2.6 inches) |
| Color options | Pacific Blue. Aluminum Silver |
| Starter | Electric |
