Modenas Karisma 125S - 2024 Specifications and Reviews

2024

2023

No pictures available
Be the first to upload a picture of this motorcycle ❮❯

General information
Type	Sport
Year model	2024
Model name	Moto Guzzi V100 Mandello S

Engine and Transmission Specifications
Emission details	Euro 5
Greenhouse gases	109.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption	4.70 litres/100 km (21.3 km/l or 50.05 mpg)
Clutch	Oil lubricated clutch, hydraulically operated
Transmission type	Shaft drive (cardan) (final drive)
Gearbox	6-speed
Cooling system	Liquid
Fuel control	Double Overhead Cams/Twin Cam (DOHC)
Fuel system	Injection
Valves per cylinder	4
Bore x stroke	96.0 x 72.0 mm (3.8 x 2.8 inches)
Torque	105.0 Nm (10.7 kgf-m or 77.4 ft.lbs) @ 6750 RPM
Effect	115.0 HP (83.9 kW)) @ 8700 RPM
Type of engine	V2, four-stroke
Capacity:	1042.0 ccm (63.58 cubic inches)

Brakes, suspension, Frame and wheels
Wheels	Cast aluminium wheels
Rear brakes	Single disc. ABS. c, 2-piston Brembo caliper.
Diameter	320 mm (12.6 inches)
Front brakes	Double disc. ABS. 4-piston Brembo monobloc radial calipers.
Rear tire	190/70-17
Front tire	110/80-17
Rear suspension	Fully adjustable Öhlins TTX Smart EC2.0 monoshock with semi-active compression and rebound damping, remote preload adjustment
Front suspension	Fully adjustable Ø43 mm USD Öhlins Smart EC2.0 fork, with semi-active compression and rebound damping.
Physical measures and capacities
Reserve fuel capacity	3.50 litres (0.92 US gallons)
Fuel capacity	17.00 litres (4.49 US gallons)
Seat height	815 mm (32.1 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc	233.0 kg (513.7 pounds)
Other specs
Comments	Ride by Wire, 5 Riding Mode. Traction control. Cruise Control. Windshield. Heated grips.
Light	LED lights
Instruments	5-inch colour TFT instrument panel
Starter	Electric
Color options	Verde 2121, Grigio Avanguardia
