Kawasaki Vulcan 1600 Nomad - 2008 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2008 |
| Model | Kawasaki Vulcan 1600 Nomad |
Engine and Transmission Specifications | |
| Transmission typefinal drive | Shaft drive (cardan) |
| Gearbox | 5-speed |
| Cooling system | Liquid |
| Starter | Electric |
| Ignition | TCBI dual plug with digital advance |
| Fuel control | OHV |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Bore x stroke | 102.0 x 95.0 mm (4.0 x 3.7 inches) |
| Compression | 9.0:1 |
| Stroke | 4 |
| Engine type | V2 |
| Capacity: | 1552.00 ccm (94.70 cubic inches) |
| | |
Physical measures and capacities | |
| Wheelbase | 1,689 mm (66.5 inches) |
| Overall width | 1,039 mm (40.9 inches) |
| Overall length | 2,515 mm (99.0 inches) |
| Overall height | 1,506 mm (59.3 inches) |
| Seat height | 719 mm (28.3 inches) If adjustable, lowest setting. |
| Dry weight | 350.2 kg (772.0 pounds) |
Kawasaki Vulcan 1600 Nomad dimensions and frame | |
| Rear brakes | Single disc |
| Front brakes | Double disc |
| Rear tyre dimensions | 170/70-x16 |
| Front tyre dimensions | 150/80-x16 |
| Rear suspension | Dual air-assisted shocks with four-way rebound damping / 3.9 in. |
| Front suspension | 41mm hydraulic fork / 5.9 in. |
| Rake (fork angle) | 32.0° |
| Frame type | High-tensile steel, double cradle |
Speed and acceleration | |
| Color options | Metallic Diablo Black, Two-Tone: Metallic Ocean Blue / Neutron Silver, Two-Tone: Candy Fire Red / Metallic Diablo Black |
| Fuel capacity | 20.06 litres (5.30 gallons) |
