Kawasaki Vulcan 1600 Nomad - 2007 Specifications and Reviews
|
Category | Custom / cruiser |
Year | 2007 |
Model | Kawasaki Vulcan 1600 Nomad |
|
Engine and Transmission Specifications |
Transmission typefinal drive | Shaft drive (cardan) |
Gearbox | 5-speed |
Cooling system | Liquid |
Starter | Electric |
Ignition | TCBI dual plug with digital advance |
Fuel control | SOHC |
Valves per cylinder | 4 |
Fuel system | Injection |
Bore x stroke | 102.0 x 95.0 mm (4.0 x 3.7 inches) |
Compression | 9.0:1 |
Stroke | 4 |
Engine type | V2 |
Capacity: | 1552.00 ccm (94.70 cubic inches) |
Physical measures and capacities |
Wheelbase | 1,689 mm (66.5 inches) |
Overall width | 1,039 mm (40.9 inches) |
Overall length | 2,515 mm (99.0 inches) |
Overall height | 1,506 mm (59.3 inches) |
Seat height | 719 mm (28.3 inches) If adjustable, lowest setting. |
Dry weight | 350.2 kg (772.0 pounds) |
Kawasaki Vulcan 1600 Nomad dimensions and frame |
Rear brakes | Single disc |
Front brakes | Double disc |
Rear tyre dimensions | 170/70-x16 |
Front tyre dimensions | 150/80-x16 |
Rear suspension | Dual air-assisted shocks with four-way rebound damping / 3.9 in. |
Front suspension | 41mm hydraulic fork / 5.9 in. |
Rake (fork angle) | 32.0° |
Frame type | High-tensile steel, double cradle |
Speed and acceleration |
Color options | Ebony, Two-Tone: Ebony / Metallic Titanium, Two-Tone: Candy Cardinal Red / Metallic Titanium |
Fuel capacity | 20.06 litres (5.30 gallons) |
