KTM 350 EXC-F - 2024 Specifications and Reviews

2024

General information
Price as new	Do you know this bike?Click here to rate it. We miss 2 votes to show the rating.
Type	Enduro / offroad
Year model	2024
Model name	KTM 350 EXC-F
Engine and Transmission Specifications
Greenhouse gases	88.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption	3.83 litres/100 km (26.1 km/l or 61.42 mpg)
Driveline	X-ring 5/8 x 1/4´ chain
Clutch	Wet, DDS multi-disc clutch, Brembo hydraulics
Transmission type	Chain (final drive)
Gearbox	6-speed
Cooling system	Liquid
Ignition	Keihin EMS
Fuel control	Double Overhead Cams/Twin Cam (DOHC)
Fuel system	Injection
Bore x stroke	88.0 x 57.5 mm (3.5 x 2.3 inches)
Type of engine	Single cylinder, four-stroke
Capacity:	349.7 ccm (21.34 cubic inches)

Brakes, suspension, Frame and wheels
Rear brakes	Single disc. Brake calipers on floating bearings
Diameter	260 mm (10.2 inches)
Front brakes	Single disc. Brake calipers on floating bearings
Rear tire	2.15-19
Front tire	1.6-21
Rear wheel travel	310 mm (12.2 inches)
Rear suspension	WP Xplor PDS shock absorber
Front wheel travel	300 mm (11.8 inches)
Front suspension	WP XPLOR-USD, Ø 48 mm
Rake (fork angle)	26.5°
Frame type	Central double-cradle-type 25CrMo4 steel

Physical measures and capacities
Fuel capacity	9.20 litres (2.43 US gallons)
Ground clearance	355 mm (14.0 inches)
Seat height	960 mm (37.8 inches) If adjustable, lowest setting.
Dry weight	103.8 kg (228.8 pounds)
Other specs
Update specs
Electrical	2 Ah lithium-ion battery
Starter	Electric
Color options	Orange/white/blue
