Honda CB300R - 2024 Specifications and Reviews
General information | |
| Price as new | Do you know this bike?Click here to rate it. We miss 2 votes to show the rating. |
| Type | Cross / motocross |
| Year of manufacture | 2024 |
| Model | Honda CRF250F |
| | |
Engine and Transmission Specifications | |
| Emission details | Meets California Air Resources Board (CARB) and EPA off-road emissions standards. |
| Driveline | #520 O-ring-sealed chain; 13T/50T |
| Transmission type | Chain (final drive) |
| Gearbox | 5-speed |
| Cooling system | Air |
| Ignition | Full Transistorized |
| Fuel control | Single Overhead Cams (SOHC) |
| Fuel system | Injection. Fuel-injection, 34mm throttle bore |
| Valves per cylinder | 4 |
| Bore x stroke | 71.0 x 63.0 mm (2.8 x 2.5 inches) |
| Compression | 9.6:1 |
| Type of engine | Single cylinder, four-stroke |
| Capacity: | 250.0 ccm (15.26 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc |
| Diameter | 240 mm (9.4 inches) |
| Front brakes | Single disc |
| Rear tire | 100/100-18 |
| Front tire | 80/100-21 |
| Rear wheel travel | 231 mm (9.1 inches) |
| Rear suspension | Pro-Link® Showa single shock with spring-preload adjustability |
| Front wheel travel | 216 mm (8.5 inches) |
| Front suspension | 41mm leading-axle Showa fork |
| Trail | 102 mm (4.0 inches) |
| Rake (fork angle) | 26.1° |
Physical measures and capacities | |
| Fuel capacity | 6.06 litres (1.60 US gallons) |
| Wheelbase | 1420 mm (55.9 inches) |
| Ground clearance | 287 mm (11.3 inches) |
| Seat height | 884 mm (34.8 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 120.2 kg (265.0 pounds) |
Other specs | |
| Comments | Model ID:CRF250F. |
| Factory warranty | Six months transferable, limited warranty |
| Starter | Electric |
| Color options | Red |
Maintenance and service data | |
| Sprockets | 13/50 (front/rear) |
