Harley-Davidson XL883L Sportster 883 Low - 2008 Specifications and Reviews
2008
General information | |
| Category | Custom / cruiser |
| Year | 2008 |
| Model | Harley-Davidson XL883L Sportster 883 Low |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, staggered shorty exhaust with dual mufflers |
| Greenhouse gases | 90.9 CO |
| Fuel consumption | 3.92 litres/100 km (25.5 km/l or 60.01 mpg) |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 5-speed |
| Cooling system | Air |
| Fuel system | Injection |
| Bore x stroke | 76.2 x 96.8 mm (3.0 x 3.8 inches) |
| Compression | 8.9:1 |
| Torque | 74.58 Nm (7.6 kgf-m or 55.0 ft.lbs) @ 3500 |
| Engine type | V2, four-stroke |
| Capacity: | 883.32 ccm (53.90 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc |
| Front brakes | Single disc |
| Rear tyre dimensions | 150/80-B16 |
| Front tyre dimensions | 100/90-H19 |
| Trail | 117 mm (4.6 inches) |
| Rake (fork angle) | 29.6° |
| | |
Physical measures and capacities | |
| Fuel capacity | 12.49 litres (3.30 gallons) |
| Wheelbase | 1,524 mm (60.0 inches) |
| Ground clearance | 1,000 mm (39.4 inches) |
| Overall length | 2,263 mm (89.1 inches) |
| Seat height | 668 mm (26.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 264.4 kg (583.0 pounds) |
| Dry weight | 255.4 kg (563.0 pounds) |
Other specs | |
| Color options | Vivid Black, Pewter Pearl, White Gold Pearl, Dark Blue Pearl, Crimson Red Sunglo. |
| Starter | Electric |
