Harley-Davidson Road King - 2014 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2014 |
| Model | Harley-Davidson Road King |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Greenhouse gases | 129.9 CO |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Driveline | Chain, 34/46 ratio primary drive |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Dry sump |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Bore x stroke | 98.4 x 111.3 mm (3.9 x 4.4 inches) |
| Compression | 9.6:1 |
| Torque | 135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250 |
| Engine details | Air-cooled Twin Cam 103™ with Integrated Oil-Cooler |
| Engine type | V2, four-stroke |
| Capacity: | 1687.97 ccm (103.00 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, 28-spoke Cast Aluminum |
| Rear brakes | Single disc. 2-piston |
| Front brakes | Single disc. 4-piston |
| Rear tyre dimensions | 180/65-B16 |
| Front tyre dimensions | 130/80-B17 |
| Trail | 170 mm (6.7 inches) |
| Rake (fork angle) | 26.0° |
| | |
Physical measures and capacities | |
| Oil capacity | 3.80 litres (0.25 quarts) |
| Fuel capacity | 22.71 litres (6.00 gallons) |
| Wheelbase | 1,613 mm (63.5 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,464 mm (97.0 inches) |
| Seat height | 678 mm (26.7 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 367.9 kg (811.0 pounds) |
| Dry weight | 355.2 kg (783.0 pounds) |
Other specs | |
| Starter | Electric |
| Overall width | 625 mm (24.6 inches) |
| Overall height | 1,005 mm (39.6 inches) |
| Power/weight ratio | 0.0383 HP/kg |
| Rear tyre | 80/100-10 |
| Front tyre | 80/100-10 |
| Rear Suspension | Single Hydraulic Shock Absorber |
| Front Suspension | Dual Hydraulic Shock Absorber |
| Frame type | Steel tube |
| Emission details | Zero emission |
| Top speed | 45.0 km/h (28.0 mph) |
| Power | 2.15 Horsepower">HP (1.6 Kilowatt">kW)) |
| Model | GreenTrans EM80 |
| Comments | Windshield |
| Color options | Sand Pearl/Canyon Brown Pearl,Amber Whiskey/Brilliant Silver, Big Blue Pearl/Vivid Black,Mysterious Red Sunglo,Brilliant Silver Pearl,Vivid Black |
| Carrying capacity | Saddle bags |
| Light | High beam, running lights, front fender running lights, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional) |
| Instruments | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light |
