Harley-Davidson FLSTC Heritage Softail Classic - 2011 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2011 |
| Model | Harley-Davidson FLSTC Heritage Softail Classic |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, staggered shorty exhaust with dual mufflers |
| Driveline | Primary Drive: Chain, 34/46 ratio. Final Drive: Belt, 32/66 ratio |
| Clutch | 9-plate, wet |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Dry-sump |
| Fuel control | DOHC |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Valves per cylinder | 2 |
| Bore x stroke | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
| Compression | 9.2:1 |
| Torque | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 3000 |
| Engine details | Twin Cam 96B. |
| Engine type | V2, four-stroke |
| Capacity: | 1584.00 ccm (96.66 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | Chrome, Laced Steel |
| Rear brakes diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc. 2-piston. Optional ABS. |
| Front brakes diameter | 292 mm (11.5 inches) |
| Front brakes | Single disc. 4-piston. Optional ABS. |
| Rear tyre dimensions | 150/80-B16 |
| Front tyre dimensions | MT90-B16 |
| Rear suspension travel | 109 mm (4.3 inches) |
| Rear suspension | Hidden, horizontal-mounted, coil-over |
| Front suspension travel | 130 mm (5.1 inches) |
| Front suspension | 41.3mm telescopic, beer can covers |
| Trail | 147 mm (5.8 inches) |
| Rake (fork angle) | 31.0° |
| Frame type | Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded. |
| | |
Physical measures and capacities | |
| Oil capacity | 3.30 litres (0.22 quarts) |
| Fuel capacity | 19.70 litres (5.20 gallons) |
| Wheelbase | 1,638 mm (64.5 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall width | 955 mm (37.6 inches) |
| Overall length | 2,400 mm (94.5 inches) |
| Overall height | 1,402 mm (55.2 inches) |
| Seat height | 688 mm (27.1 inches) If adjustable, lowest setting. |
| Dry weight | 331.1 kg (730.0 pounds) |
Other specs | |
| Carrying capacity | Front and rear rack |
| Wheelbase | 1,490 mm (58.7 inches) |
| Power/weight ratio | 0.1114 HP/kg |
| Rear tyre | 25/10-12 |
| Front tyre | 25/8-12 |
| Rear Suspension | Gas shocks with pre-load adjustment |
| Front Suspension | Independent double A-arm |
| Transmission type,final drive | Chain |
| Ignition | CDI |
| Bore x Stroke | 96.0 x 82.0 mm (3.8 x 3.2 inches) |
| Compression | 10.2:1 |
| Torque | 46.90 Nm (4.8 kgf-m or 34.6 ft.lbs) |
| Power | 37.55 Horsepower">HP (27.4 Kilowatt">kW)) |
| Capacity: | 594.00 ccm (36.25 cubic inches) |
| Model | Goes G 625i Max |
| Color options | Vivid Black, Brilliant Silver Pearl, Chrome Yellow, Merlot Sunglo/Vivid Black, Cool Blue Pearl/Vivid Black, Psychedelic Purple/Vivid Black, Apple Green/Vivid Black, Arctic White, Concord Purple, Vivid Black, Fire Engine Red, Dark Peace Officer |
| Light | 55-watt low beam, 60-watt high beam |
| Instruments | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed ind |
| Starter | Electric |
