Harley-Davidson FLSTCI Heritage Softail Classic - 2005 Specifications and Reviews
General information | |
| Category | Custom / cruiser |
| Year | 2005 |
| Model | Harley-Davidson FLSTCI Heritage Softail Classic |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Staggered shorty duals |
| Clutch | Multi-plate clutch with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 5-speed |
| Cooling system | Air |
| Fuel control | DOHC |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI ) |
| Bore x stroke | 95.3 x 101.6 mm (3.8 x 4.0 inches) |
| Compression | 8.8:1 |
| Torque | 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 3500 |
| Engine type | V2, four-stroke |
| Capacity: | 1449.00 ccm (88.42 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 292 mm (11.5 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 150/80-B16 |
| Front tyre dimensions | MT90-B16 |
| Rake (fork angle) | 32.0° |
| | |
Physical measures and capacities | |
| Fuel capacity | 18.90 litres (4.99 gallons) |
| Wheelbase | 1,630 mm (64.2 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,391 mm (94.1 inches) |
| Seat height | 648 mm (25.5 inches) If adjustable, lowest setting. |
| Dry weight | 322.0 kg (709.9 pounds) |
Other specs | |
| Color options | Vivid black, brilliant silver pearl, black cherry pearl, lava red sunglo, glacier white pearl, rich sunglo blue, two-tone rich sunglo blue and chopper blue pearl, two-tone black cherry pearl and black pearl, two-tone sierra red pearl and brilliant silver |
