Harley-Davidson FLHTCU Ultra Classic Electra Glide - 2012 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2012 |
| Model | Harley-Davidson FLHTCU Ultra Classic Electra Glide |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Greenhouse gases | 129.9 CO |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Driveline | Primary drive chain, 34/46 ratio. Final Drive Belt, 32/68 ratio |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Pressurized, dry-sump with oil cooler |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Valves per cylinder | 2 |
| Bore x stroke | 98.4 x 111.3 mm (3.9 x 4.4 inches) |
| Compression | 9.6:1 |
| Torque | 135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3250 |
| Engine details | Air-cooled Twin Cam 103 with Integrated Oil-Cooler |
| Engine type | V2, four-stroke |
| Capacity: | 1687.97 ccm (103.00 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, 28-spoke Cast Aluminum |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc. 4-piston caliper. Optional ABS. |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc. 4-piston calipers. Optional ABS. |
| Rear tyre dimensions | 180/65-NW16 |
| Front tyre dimensions | 130/80-NW17 |
| Rear suspension travel | 76 mm (3.0 inches) |
| Rear suspension | Air-adjustable shocks. Mild steel; two-piece drawn and welded section; forged junctions; MIG welded swingarm. |
| Front suspension travel | 117 mm (4.6 inches) |
| Front suspension | 41.3 mm telescopic, triple circuit damping |
| Trail | 170 mm (6.7 inches) |
| Rake (fork angle) | 26.0° |
| Frame type | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded |
Physical measures and capacities | |
| Oil capacity | 3.80 litres (0.25 quarts) |
| Fuel capacity | 22.71 litres (6.00 gallons) |
| Wheelbase | 1,613 mm (63.5 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,504 mm (98.6 inches) |
| Seat height | 693 mm (27.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 403.2 kg (889.0 pounds) |
| Dry weight | 386.5 kg (852.0 pounds) |
| | |
Other specs | |
| Comments | French brand. |
| Wheelbase | 1,285 mm (50.6 inches) |
| Overall width | 685 mm (27.0 inches) |
| Overall height | 1,150 mm (45.3 inches) |
| Power/weight ratio | 0.0472 HP/kg |
| Rear tyre | 3.00-12 |
| Front tyre | 2.50-12 |
| Ignition | CDI |
| Torque | 4.00 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5500 Revolutions">RPM |
| Power | 4.15 Horsepower">HP (3.0 Kilowatt">kW)) @ 8000 Revolutions">RPM |
| Capacity: | 49.20 ccm (3.00 cubic inches) |
| Model | Goes G 55 R Sport |
| Color options | Vivid Black, Ember Red Sunglo, White Hot Pearl, Big Blue Pearl/Vivid Black, Ember Red Sunglo/Merlot Sunglo, Tequila Sunrise/H-D Orange |
| Factory warranty | 2 years, unlimited mileage. |
| Seat | One-piece, two-up Electra Glide classic comfort stitch seat, sculpted for added comfort and easier straddling. Passenger backrest with wrap-around armrests. |
| Electrical | Sealed, maintenance-free battery, 12V, 28-amp/hour, 370 cca |
| Light | 55-watt low beam, 60-watt high beam headlight |
| Instruments | Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light; cruise control indicator light; tachometer with fuel, voltage, oil pressure and ambient air temperature gauges |
| Starter | Electric |
