Yamaha XJR 1300 - 2009 Specifications and Reviews
General information | |
| Category | Naked bike |
| Year | 2009 |
| Model | Yamaha XJR 1300 |
Engine and Transmission Specifications | |
| Clutch | Wet, multiple-disc coil spring |
| Transmission typefinal drive | Chain |
| Gearbox | 5-speed |
| Cooling system | Air |
| Lubrication system | Wet sump |
| Starter | Electric |
| Ignition | TCI |
| Fuel control | DOHC |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Bore x stroke | 79.0 x 63.8 mm (3.1 x 2.5 inches) |
| Compression | 9.7:1 |
| Torque | 108.40 |
| Power | 96.41 |
| Stroke | 4 |
| Engine type | In-line four |
| Capacity: | 1251.00 ccm (76.34 cubic inches) |
Physical measures and capacities | |
| Wheelbase | 1,500 mm (59.1 inches) |
| Ground clearance | 125 mm (4.9 inches) |
| Overall width | 765 mm (30.1 inches) |
| Overall length | 2,175 mm (85.6 inches) |
| Overall height | 1,115 mm (43.9 inches) |
| Seat height | 795 mm (31.3 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 245.0 kg (540.1 pounds) |
| | |
Yamaha XJR 1300 dimensions and frame | |
| Rear brakes diameter | 267 mm (10.5 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 298 mm (11.7 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 180/55-ZR17 |
| Front tyre dimensions | 120/70-ZR17 |
| Rear suspension travel | 120 mm (4.7 inches) |
| Rear suspension | Swingarm |
| Front suspension travel | 130 mm (5.1 inches) |
| Front suspension | Telescopic forks |
| Trail | 100 mm (3.9 inches) |
| Frame type | Steel double cradle |
| | |
Speed and acceleration | |
| Color options | Silver, black |
| Oil capacity | 4.20 litres (0.28 quarts) |
| Fuel capacity | 21.00 litres (5.55 gallons) |
