Yamaha V Star 1300 - 2007 Specifications and Reviews
|
Category | Custom / cruiser |
Year | 2007 |
Model | Yamaha V Star 1300 |
Engine and Transmission Specifications |
Gearbox | 5-speed |
Cooling system | Liquid |
Ignition | T.C.I. |
Fuel control | OHC |
Fuel system | Injection |
Valves per cylinder | 4 |
Bore x stroke | 100.0 x 83.0 mm (3.9 x 3.3 inches) |
Compression | 9.5:1 |
Engine type | V2, four-stroke |
Capacity: | 1311.05 ccm (80.00 cubic inches) |
|
Brakes, suspension, Frame and wheels |
Rear brakes diameter | 298 mm (11.7 inches) |
Rear brakes | Single disc |
Front brakes diameter | 298 mm (11.7 inches) |
Front brakes | Double disc |
Rear tyre dimensions | 170/70-B16 |
Front tyre dimensions | 130/90-M16 |
Rear suspension | Swingarm, Coil Spring/gas-oil damper, 4.33´ |
Front suspension | Telescopic Fork, Coil Spring/oil damper, 5.31´ |
Frame type | Double Cradle |
|
Physical measures and capacities |
Fuel capacity | 18.47 litres (4.88 gallons) |
Wheelbase | 1,690 mm (66.5 inches) |
Overall width | 980 mm (38.6 inches) |
Overall length | 2,490 mm (98.0 inches) |
Seat height | 714 mm (28.1 inches) If adjustable, lowest setting. |
Dry weight | 283.0 kg (623.9 pounds) |
Other specs |
Color options | Raven, blue, red |
Starter | Electric |
