Yamaha Road Star S - 2014 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryCustom / cruiser
Year2014
ModelYamaha Road Star S



Engine and Transmission Specifications

Exhaust systemTwo-into-two exhaust
Greenhouse gases151.5 CO
Fuel consumption6.53 litres/100 km (15.3 km/l or 36.02 mpg)
ClutchMultiplate, wet
Transmission type,final driveBelt
Gearbox5-speed
Cooling systemAir
IgnitionTCI: Transistor Controlled Ignition
Fuel controlOHV
Fuel systemInjection
Valves per cylinder4
Bore x stroke97.0 x 113.0 mm (3.8 x 4.4 inches)
Compression8.4:1
Engine typeV2, four-stroke
Capacity:1671.58 ccm (102.00 cubic inches)

Brakes, suspension, Frame and wheels

Wheels9-spoke cast
Rear brakes diameter320 mm (12.6 inches)
Rear brakesSingle disc. Hydraulic.
Front brakes diameter298 mm (11.7 inches)
Front brakesDouble disc. Hydraulic.
Rear tyre dimensions150/80-B16
Front tyre dimensions130/90-M16
Rear suspension travel109 mm (4.3 inches)
Rear suspensionSingle shock
Front suspension travel140 mm (5.5 inches)
Front suspension43mm fork
Frame typeSteel, hidden shock

Physical measures and capacities

Fuel capacity18.17 litres (4.80 gallons)
Wheelbase1,689 mm (66.5 inches)
Ground clearance145 mm (5.7 inches)
Overall width980 mm (38.6 inches)
Overall length2,499 mm (98.4 inches)
Overall height1,140 mm (44.9 inches)
Seat height709 mm (27.9 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc337.0 kg (743.0 pounds)

Other specs

Comments4500 Ah Lithium Polymer battery. Range 75km. XOR is an abbreviation of Xtraordinary Object on Road. Foldable bike. French brand.
Carrying capacityBoot for integral helmet
LightLED lights
InstrumentsDigital
Wheelbase1,303 mm (51.3 inches)
Power/weight ratio0.1819 HP/kg
Dry weight59.0 kg (130.1 pounds)
Seat2 people seat
Rear tyre130/60-13
Front tyre100/80-10
Rear SuspensionSilent block
Front SuspensionHydraulic
Emission detailsNo direct emission
0-100 km/h (0-62 mph)6.000 seconds
Top speed120.0 km/h (74.6 mph)
Power10.73 Horsepower">HP (7.8 Kilowatt">kW))
Engine detailsBrushless in rear wheel hub
ModelXOR XO2 8.0KW
Color optionsNebulous Purple
Factory warranty1 Year (Limited Factory Warranty)
StarterElectric
