Victory Vision Tour - 2010 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2010 |
| Model | Victory Vision Tour |
| | |
Engine and Transmission Specifications | |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Oil & air |
| Fuel control | SOHC |
| Fuel system | Injection. Dual 45mm throttle body |
| Valves per cylinder | 4 |
| Bore x stroke | 101.0 x 108.0 mm (4.0 x 4.3 inches) |
| Compression | 9.4:1 |
| Power | 97.00 |
| Engine type | V2, four-stroke |
| Capacity: | 1731.00 ccm (105.63 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc. 2-piston caliper |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc. 3-piston caliper |
| Rear tyre dimensions | 180/60-16 |
| Front tyre dimensions | 130/70-18 |
| Rear suspension travel | 100 mm (3.9 inches) |
| Rear suspension | Single, mono-tube gas,cast aluminum with rising rate linkage |
| Front suspension travel | 130 mm (5.1 inches) |
| Front suspension | Conventional telescopic fork |
| Trail | 137 mm (5.4 inches) |
| Rake (fork angle) | 29.0° |
| | |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (0.31 quarts) |
| Reserve fuel capacity | 3.78 litres (1.00 gallons) |
| Fuel capacity | 22.71 litres (6.00 gallons) |
| Wheelbase | 1,669 mm (65.7 inches) |
| Ground clearance | 148 mm (5.8 inches) |
| Overall length | 2,664 mm (104.9 inches) |
| Seat height | 673 mm (26.5 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.2985 HP/kg |
| Dry weight | 325.0 kg (716.5 pounds) |
Other specs | |
| Color options | Solid Black, Solid Pearl White, Two Tone Ocean Blue and Sandstone Metallic. |
