Category | Custom / cruiser |
Year | 2014 |
Model | Victory Jackpot |
|
Engine and Transmission Specifications |
Exhaust system | Staggered slash-cut dual exhaust with crossover |
Driveline | Carbon Fiber Reinforced Belt. Primary drive: Gear drive with torque compensator. |
Clutch | Wet, multi-plate |
Transmission type,final drive | Belt |
Gearbox | 6-speed |
Cooling system | Oil & air |
Fuel control | SOHC |
Fuel system | Injection. Electronic Fuel Injection with dual 45mm throttle body |
Valves per cylinder | 4 |
Bore x stroke | 101.0 x 108.0 mm (4.0 x 4.3 inches) |
Compression | 9.4:1 |
Torque | 12.00 Nm (1.2 kgf-m or 8.9 ft.lbs) |
Engine details | Self-adjusting cam chains, hydraulic lifters |
Engine type | V2, four-stroke |
Capacity: | 1737.14 ccm (106.00 cubic inches) |
Brakes, suspension, Frame and wheels |
Wheels | 90/90 21 Dunlop Elite 3 |
Rear brakes diameter | 300 mm (11.8 inches) |
Rear brakes | Single disc. Floating disc. Two-piston calipers. |
Front brakes diameter | 300 mm (11.8 inches) |
Front brakes | Single disc. Floating discs. Four-piston calipers. |
Rear tyre dimensions | 250/40-R18 |
Rear suspension | Single, mono-tube gas, cast aluminum with rising rate linkage, 3.0 in / 75 mm travel, preload adjustable spring |
Front suspension | Conventional telescopic fork, 43 mm diameter, 5.1 in / 130 mm travel |
Trail | 124 mm (4.9 inches) |
Rake (fork angle) | 33.0° |
Physical measures and capacities |
Oil capacity | 4.70 litres (0.31 quarts) |
Fuel capacity | 17.03 litres (4.50 gallons) |
Wheelbase | 1,704 mm (67.1 inches) |
Ground clearance | 135 mm (5.3 inches) |
Overall length | 2,464 mm (97.0 inches) |
Seat height | 653 mm (25.7 inches) If adjustable, lowest setting. |
Dry weight | 296.2 kg (653.0 pounds) |
|
Other specs |
Color options | Gloss Sunset Red with Two-Tone Tank |
Electrical | 12 volts / 18 amp hours battery. |
Starter | Electric |
