Vertigo Dougie Lampkin Replica - 2023 Specifications and Reviews

2023
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryTrial
Year2023
ModelVertigo Dougie Lampkin Replica

Engine and Transmission Specifications

DrivelineRegina 103
ClutchMulti-disc oil wet, adjustable preload
Transmission typeChain   (final drive)
Gearbox4-speed
Cooling systemLiquid
Fuel systemInjection. Integrated injection driver.
Bore x Stroke79.0 x 60.0 mm (3.1 x 2.4 inches)
Power31.0 Horsepower">HP (22.6 Kilowatt">kW)) @ 9200 Revolutions">RPM
Engine typeSingle cylinder, two-stroke
Capacity:300.0 ccm (18.31 cubic inches)

Brakes, suspension, Frame and wheels

WheelsBlack Morad rims. Vertigo red hubs. Dunlop D803GP tires
Rear brakesSingle disc. 2-piston caliper
Diameter185 mm (7.3 inches)
Front brakesSingle disc. Hydraulic Braktec, 4-piston caliper
Rear tire2.15-18
Front tire1.60-21
Rear wheel travel170 mm (6.7 inches)
Rear SuspensionSwingarm combined with REIGER 2 way monoshock with compression, rebound and spring preload adjustment
Front wheel travel170 mm (6.7 inches)
Front SuspensionTech Factory
Frame typeMultitubular silver chassis 25CrMo4 steel, aluminium 6082 subframe



Physical measures and capacities

Fuel capacity2.30 litres (0.61 US gallons)
Wheelbase1310 mm (51.6 inches)
Overall length2010 mm (79.1 inches)
Seat height680 mm (26.8 inches) If adjustable, lowest setting.
Power/weight ratio0.4559 HP/kg
Dry weight68.0 kg (149.9 pounds)



Other specs

CommentsBattery assisted.
StarterElectric & kick
Color optionsGreen/black

Rider Reviews

Total comments: 1
64x64

MotorcycleDB Review

The 2023 Vertigo Dougie Lampkin Replica is a stunning tribute to the legendary trials rider, Dougie Lampkin. This limited edition bike features top-of-the-line components and a design that closely mirrors Lampkin's own competition bike. The attention to detail is impeccable, with replica graphics and signature touches that make this bike a true collector's item for fans of the legendary rider. In terms of performance, the 2023 Vertigo Dougie Lampkin Replica delivers an incredible riding experience. The lightweight frame and powerful engine make it a formidable machine on the trails, while the precision handling and responsive brakes give riders the confidence to tackle even the toughest obstacles. Whether you're a seasoned trials competitor or a dedicated fan of Dougie Lampkin, this replica bike is sure to impress with its high-performance capabilities and authentic design.
