Suzuki GSX1250FA - 2012 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategorySport
Year2012
ModelSuzuki GSX1250FA



Engine and Transmission Specifications

DrivelineRK GB50GSVZ3, 118 links
ClutchHydraulic clutch with coil springs
Transmission type,final driveChain
Gearbox6-speed
Cooling systemOil & air
Lubrication systemWet sump
IgnitionElectronic ignition (Transistorized)
Fuel controlDOHC
Fuel systemInjection
Valves per cylinder4
Bore x stroke79.0 x 64.0 mm (3.1 x 2.5 inches)
Compression10.5:1
Torque108.00 Nm (11.0 kgf-m or 79.7 ft.lbs) @ 3500
Power96.55
Engine detailsLong-wearing, tough SCEM (Suzuki Composite Electrochemical Material) cylinder-bore plating offers increased durability and efficiency. Chrome-nitride piston-ring coating.
Engine typeIn-line four, four-stroke
Capacity:1250.00 ccm (76.28 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes diameter240 mm (9.4 inches)
Rear brakesSingle disc. Digital ABS
Front brakes diameter310 mm (12.2 inches)
Front brakesDouble disc. Digital ABS
Rear tyre dimensions180/55-ZR17
Front tyre dimensions120/70-ZR17
Rear suspension travel136 mm (5.4 inches)
Rear suspensionLink type, coil spring, oil damped
Front suspension travel130 mm (5.1 inches)
Front suspensionTelescopic, coil spring, oil damped
Trail104 mm (4.1 inches)
Rake (fork angle)25.6°
Frame typeClassic tube-frame chassis, with rake and trail chosen for an excellent balance between sporty handling and highway cruising.

Physical measures and capacities

Fuel capacity18.50 litres (4.89 gallons)
Wheelbase1,485 mm (58.5 inches)
Ground clearance135 mm (5.3 inches)
Overall width790 mm (31.1 inches)
Overall length2,130 mm (83.9 inches)
Alternate seat height825 mm (32.5 inches) If adjustable, highest setting.
Seat height805 mm (31.7 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc257.0 kg (566.6 pounds)



Other specs

CommentsItalian brand.
InstrumentsElectronic/analogical rev counter and speedometer with multifunctional LCD display
Reserve fuel capacity4.50 litres (1.19 gallons)
Wheelbase1,470 mm (57.9 inches)
Power/weight ratio0.5909 HP/kg
Dry weight198.0 kg (436.5 pounds)
WheelsExcel spoke rims with aluminium channel
Rear tyre180/55-R17
Front tyre120/70-R17
Rear wheel travel150 mm (5.9 inches)
Rear SuspensionOval steel tube swin arm. Single lateral shock absorber with fully adjustable pibby tank
Front wheel travel150 mm (5.9 inches)
Front SuspensionMarzocchi upside-down fork
Exhaust system3-way catalytic converter with oxygen sensor.
Emission detailsEuro 3.
Valves per cylinder4
Bore x Stroke107.0 x 66.0 mm (4.2 x 2.6 inches)
Torque102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 Revolutions">RPM
Capacity:1187.00 ccm (72.43 cubic inches)
ModelMoto Morini 9 1-2
Color optionsBlack
Factory warranty12 Month Limited Warranty
LightVertically stacked headlights
StarterElectric
