Suzuki DR-Z400SM - 2018 Specifications and Reviews
General information | |
Category | Super motard |
Year | 2018 |
Model | Suzuki DR-Z400SM |
| |
Engine and Transmission Specifications | |
Driveline | RK520KZO, 110 links |
Clutch | Multi-plate, wet type, manual release |
Transmission type,final drive | Chain |
Gearbox | 5-speed |
Cooling system | Liquid |
Lubrication system | Semi-dry sump |
Ignition | CDI |
Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
Fuel system | Carburettor. Mikuni BSR36, single |
Valves per cylinder | 4 |
Bore x Stroke | 90.0 x 62.6 mm (3.5 x 2.5 inches) |
Compression | 11.3:1 |
Engine type | Single cylinder, four-stroke |
| |
Brakes, suspension, Frame and wheels | |
Wheels | Gold-anodized RK Excel aluminum rims with stainless steel spokes |
Rear brakes diameter | 240 mm (9.4 inches) |
Rear brakes | Single disc |
Front brakes diameter | 300 mm (11.8 inches) |
Front brakes | Single disc. Floating rotor |
Rear tyre | 140/70-17 |
Front tyre | 120/70-17 |
Rear Suspension | Link type, coil spring, oil damped, adjustable spring preload |
Front Suspension | Inverted telescopic, coil spring, oil damped |
Physical measures and capacities | |
Fuel capacity | 9.84 litres (2.60 gallons) |
Wheelbase | 1,460 mm (57.5 inches) |
Ground clearance | 260 mm (10.2 inches) |
Overall width | 855 mm (33.7 inches) |
Overall length | 2,225 mm (87.6 inches) |
Overall height | 1,200 mm (47.2 inches) |
Seat height | 890 mm (35.0 inches) If adjustable, lowest setting. |
Weight incl. oil, gas, etc | 146.0 kg (321.9 pounds) |
Other specs | |
Factory warranty | 12 month unlimited mileage limited warranty. |
Light | On-road legal lighting with bright 60/55 watt halogen headlight. |
Starter | Electric |
Color options | Solid Black |
