Suzuki Boulevard M50 - 2005 Specifications and Reviews
General information | |
| Category | Custom / cruiser |
| Year | 2005 |
| Model | Suzuki Boulevard M50 |
| | |
Engine and Transmission Specifications | |
| Transmission typefinal drive | Shaft drive (cardan) |
| Gearbox | 5-speed |
| Cooling system | Liquid |
| Starter | Electric |
| Fuel control | SOHC |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Bore x stroke | 83.0 x 74.4 mm (3.3 x 2.9 inches) |
| Compression | 9.4:1 |
| Stroke | 4 |
| Engine type | V2 |
| Capacity: | 819.40 ccm (50.00 cubic inches) |
| | |
Physical measures and capacities | |
| Wheelbase | 1,655 mm (65.2 inches) |
| Ground clearance | 140 mm (5.5 inches) |
| Overall width | 860 mm (33.9 inches) |
| Overall length | 2,370 mm (93.3 inches) |
| Overall height | 1,130 mm (44.5 inches) |
| Seat height | 700 mm (27.6 inches) If adjustable, lowest setting. |
| Dry weight | 245.0 kg (540.1 pounds) |
Suzuki Boulevard M50 dimensions and frame | |
| Rear brakes | Single disc |
| Front brakes | Single disc |
| Rear tyre dimensions | 170/80-15 |
| Front tyre dimensions | 130/90-16 |
| Rear suspension | Link-type, oil damped, 7-way adjustable spring preload |
| Front suspension | Inverted, telescopic, coil spring, oil damped |
| Frame type | Soft-tail-style frame creates a continuous flowing line from the headlight, through the fuel tank, seat and rear fender |
Speed and acceleration | |
| Color options | Blue, Red |
| Fuel capacity | 15.50 litres (4.10 gallons) |
