Suzuki AX4 Evolution - 2023 Specifications and Reviews
2023
General information | |
Category | Allround |
Year | 2023 |
Model | Suzuki AX4 Evolution |
Engine and Transmission Specifications | |
Emission details | Euro 3 |
Clutch | Wet, multi-disc |
Transmission type | Chain (final drive) |
Gearbox | 4-speed |
Cooling system | Air |
Lubrication system | Wet sump |
Ignition | CD-CDI |
Fuel control | Single Overhead Cams (SOHC) |
Fuel system | Carburettor. Mikuni BS22 |
Bore x Stroke | 51.0 x 55.2 mm (2.0 x 2.2 inches) |
Compression | 9.5:1 |
Torque | 7.8 Nm (0.8 kgf-m or 5.8 ft.lbs) @ 5000 Revolutions">RPM |
Power | 8.0 Horsepower">HP (5.8 Kilowatt">kW)) @ 8000 Revolutions">RPM |
Engine type | Single cylinder, four-stroke |
Capacity: | 113.0 ccm (6.90 cubic inches) |
Brakes, suspension, Frame and wheels | |
Rear brakes | Expanding brake (drum brake) |
Front brakes | Expanding brake (drum brake) |
Rear tire | 2.75-17 |
Front tire | 2.50-17 |
Rear Suspension | Swingarm type, oil damped, dual shocks |
Front Suspension | Telescopic, coil spring, oil damped |
| |
Physical measures and capacities | |
Reserve fuel capacity | 1.80 litres (0.48 US gallons) |
Fuel capacity | 9.20 litres (2.43 US gallons) |
Wheelbase | 1215 mm (47.8 inches) |
Ground clearance | 140 mm (5.5 inches) |
Overall width | 750 mm (29.5 inches) |
Overall length | 1900 mm (74.8 inches) |
Overall height | 1050 mm (41.3 inches) |
Seat height | 766 mm (30.2 inches) If adjustable, lowest setting. |
Weight incl. oil, gas, etc | 108.0 kg (238.1 pounds) |
Other specs | |
Comments | Sold in South America. |
Starter | Electric & kick |
Color options | Red, Black, Blue |
