Moto Morini Granpasso H83 - 2012 Specifications and Reviews
General information | |
| Category | Allround |
| Year | 2012 |
| Model | Moto Morini Granpasso H83 |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Ilencer with 3-way catalytic converter with oxygen sensor |
| Driveline | With constant mesh spur gears |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Forced |
| Ignition | I.A.W. electronics |
| Fuel control | DOHC |
| Fuel system | Injection |
| Valves per cylinder | 4 |
| Compression | 12.5:1 |
| Torque | 103.60 Nm (10.6 kgf-m or 76.4 ft.lbs) @ 7000 |
| Power | 118.00 |
| Engine details | Moto Morini Bialbero CorsaCorta |
| Engine type | V2, four-stroke |
| Capacity: | 1187.00 ccm (72.43 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Excel spoke rims with aluminium channel |
| Rear brakes diameter | 255 mm (10.0 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 298 mm (11.7 inches) |
| Front brakes | Double disc |
| Rear tyre dimensions | 150/70-R17 |
| Front tyre dimensions | 110/80-R19 |
| Rear suspension travel | 200 mm (7.9 inches) |
| Rear suspension | Ohlins single shock absorber |
| Front suspension travel | 190 mm (7.5 inches) |
| Front suspension | Marzocchi upside down |
| Trail | 110 mm (4.3 inches) |
| Rake (fork angle) | 26.5° |
| Frame type | Verlicchi high-strength steel tube trellis frame |
Physical measures and capacities | |
| Reserve fuel capacity | 5.50 litres (1.45 gallons) |
| Fuel capacity | 27.00 litres (7.13 gallons) |
| Ground clearance | 200 mm (7.9 inches) |
| Overall length | 2,170 mm (85.4 inches) |
| Seat height | 830 mm (32.7 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.5619 HP/kg |
| Dry weight | 210.0 kg (463.0 pounds) |
Other specs | |
| Comments | Italian brand. |
| Factory warranty | 3 years |
| Wheelbase | 1,470 mm (57.9 inches) |
| Overall width | 865 mm (34.1 inches) |
| Rear tyre | 180/55-R17 |
| Front tyre | 120/70-R17 |
| Rear wheel travel | 150 mm (5.9 inches) |
| Rear Suspension | Oval steel tube swin arm. Single lateral shock absorber with fully adjustable pibby tank |
| Front wheel travel | 150 mm (5.9 inches) |
| Front Suspension | Marzocchi upside-down fork |
| Emission details | Euro 3. |
| Clutch | Wet, multi-plate |
| Valves per cylinder | 4 |
| Bore x Stroke | 107.0 x 66.0 mm (4.2 x 2.6 inches) |
| Torque | 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 Revolutions">RPM |
| Capacity: | 1187.00 ccm (72.43 cubic inches) |
| Model | Moto Morini 9 1-2 |
| Color options | Silver, white, red |
| Instruments | Electronic rev counter and speedometer with multifunctional LCD display |
| Starter | Electric |
