KTM 350 EXC-F Six Days - 2012 Specifications and Reviews
General information | |
| Category | Enduro / offroad |
| Year | 2012 |
| Model | KTM 350 EXC-F Six Days |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Aluminium |
| Driveline | 14:52 (13:52). Primary ratio 24:73. X-Ring 5/8 x 1/4. |
| Clutch | Wet multi-disc clutch, Brembo hydraulics |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Pressure lubrication with 2 oil pumps |
| Ignition | Keihin EMS |
| Fuel control | DOHC |
| Fuel system | Injection. Keihin EFI, flow restrictor 42 mm |
| Valves per cylinder | 4 |
| Bore x stroke | 88.0 x 57.5 mm (3.5 x 2.3 inches) |
| Compression | 12.3:1 |
| Engine details | DOHC with finger followers |
| Engine type | Single cylinder, four-stroke |
| Capacity: | 349.70 ccm (21.34 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Wheels | 1.60 x 21; 2.15 x 18 Excel |
| Rear brakes diameter | 220 mm (8.7 inches) |
| Rear brakes | Single disc |
| Front brakes diameter | 260 mm (10.2 inches) |
| Front brakes | Single disc |
| Rear tyre dimensions | 110/90-19 |
| Front tyre dimensions | 90/90-21 |
| Rear suspension travel | 335 mm (13.2 inches) |
| Rear suspension | WP-PDS shock absorber |
| Front suspension travel | 300 mm (11.8 inches) |
| Front suspension | WP-USD 48 mm |
| Rake (fork angle) | 26.5° |
| Frame type | Central double-cradle-type 25CrMo4. Subframe: Aluminium. |
| | |
Physical measures and capacities | |
| Fuel capacity | 9.50 litres (2.51 gallons) |
| Wheelbase | 1,482 mm (58.3 inches) |
| Ground clearance | 345 mm (13.6 inches) |
| Seat height | 970 mm (38.2 inches) If adjustable, lowest setting. |
| Dry weight | 107.5 kg (237.0 pounds) |
Other specs | |
| Factory warranty | 12 Months |
| Light | 30W x 2 halogen |
| Wheelbase | 1,255 mm (49.4 inches) |
| Overall width | 1,204 mm (47.4 inches) |
| Overall length | 2,065 mm (81.3 inches) |
| Overall height | 1,146 mm (45.1 inches) |
| Weight incl. oil, gas, etc | 292.1 kg (643.9 pounds) |
| Rear tyre | 25/10-12 |
| Front tyre | 25/8-12 |
| Rear Suspension | Swingarm with single shock, preload adjustment / 7.1 in. |
| Front Suspension | MacPherson strut / 6.7 in. |
| Bore x Stroke | 80.0 x 72.0 mm (3.1 x 2.8 inches) |
| Compression | 8.3:1 |
| Model | Kawasaki Prairie 360 4x4 Realtree APG HD |
| Color options | Orange/blue/white/black |
| Starter | Electric & kick |
