KTM 1190 Adventure - 2015 Specifications and Reviews
General information | |
| Category | Allround |
| Year | 2015 |
| Model | KTM 1190 Adventure |
Engine and Transmission Specifications | |
| Driveline | 5/8 x 5/16 X Ring. Primary drive: 40:76. |
| Clutch | Slipper clutch |
| Transmission type,final drive | Chain |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Lubrication system | Forced oil lubrication with 3 rotor pumps |
| Ignition | Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment |
| Fuel system | Injection |
| Bore x Stroke | 105.0 x 69.0 mm (4.1 x 2.7 inches) |
| Power | 150.00 Horsepower">HP (109.5 Kilowatt">kW)) |
| Engine details | V-twin with its 75° cylinder angle |
| Engine type | V2, four-stroke |
| Capacity: | 1195.00 ccm (72.92 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 267 mm (10.5 inches) |
| Rear brakes | Single disc. ABS. Two-piston calipers. |
| Front brakes diameter | 320 mm (12.6 inches) |
| Front brakes | Double disc. ABS. Four-piston calipers. Radially mounted. |
| Rear wheel travel | 190 mm (7.5 inches) |
| Rear Suspension | WP Suspension monoshock |
| Front wheel travel | 190 mm (7.5 inches) |
| Front Suspension | WP Suspension Up Side Down |
| Rake (fork angle) | 26.0° |
| Frame type | Tubular space frame made from chrome molybdenum steel, powder-coated |
| | |
Physical measures and capacities | |
| Fuel capacity | 23.00 litres (6.08 gallons) |
| Wheelbase | 1,560 mm (61.4 inches) |
| Ground clearance | 220 mm (8.7 inches) |
| Alternate seat height | 875 mm (34.4 inches) If adjustable, highest setting. |
| Seat height | 860 mm (33.9 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.7075 HP/kg |
| Dry weight | 212.0 kg (467.4 pounds) |
Other specs | |
| Comments | Small windscreen. Ride-by-wire system. Traction Control. |
| Starter | Electric |
| Color options | White, Orange |
