Indian Springfield Dark Horse - 2020 Specifications and Reviews
General information | |
Category | Touring |
Year | 2020 |
Model | Indian Springfield Dark Horse |
Engine and Transmission Specifications | |
Exhaust system | Split dual exhaust with cross-over |
Clutch | Wet multi-plate |
Transmission type | Belt (final drive) |
Gearbox | 6-speed |
Cooling system | Air |
Fuel system | Injection. Closed Loop Sequential Port Fuel Injection |
Bore x Stroke | 103.0 x 113.0 mm (4.1 x 4.4 inches) |
Compression | 11.1:1 |
Torque | 161.4 Nm (16.5 kgf-m or 119.0 ft.lbs) @ 3000 Revolutions">RPM |
Engine details | Thunder Stroke® 111 engine, blacked out |
Engine type | V2, four-stroke |
Capacity: | 1811.0 ccm (110.51 cubic inches) |
Brakes, suspension, Frame and wheels | |
Seat | Dual leather seat |
Wheels | Cast aluminium wheels |
Rear brakes | Single disc. ABS. Floating disc. 2-piston caliper. |
Diameter | 300 mm (11.8 inches) |
Front brakes | Double disc. ABS. Floating discs. 4 piston caliper. |
Rear tire | 180/60-B16 |
Front tire | 130/90-B16 |
Rear wheel travel | 114 mm (4.5 inches) |
Rear Suspension | Single shock |
Front wheel travel | 119 mm (4.7 inches) |
Front Suspension | Telescopic forks with air adjust |
Trail | 133 mm (5.2 inches) |
Rake (fork angle) | 25.0° |
Frame type | Cast Aluminum Frame with Integrated Air-Box |
| |
Physical measures and capacities | |
Fuel capacity | 20.80 litres (5.50 US gallons) |
Wheelbase | 1701 mm (67.0 inches) |
Ground clearance | 133 mm (5.2 inches) |
Overall width | 1000 mm (39.4 inches) |
Overall length | 2522 mm (99.3 inches) |
Overall height | 1176 mm (46.3 inches) |
Seat height | 660 mm (26.0 inches) If adjustable, lowest setting. |
Weight incl. oil, gas, etc | 360.0 kg (793.7 pounds) |
Dry weight | 349.0 kg (769.4 pounds) |
Other specs | |
Factory warranty | 2 years |
Carrying capacity | Hard saddle bags. |
Light | Tear drop head lamp, spot lights, fender light |
Instruments | Tank Mounted Electronic Speedometer with Odometer; Dual Tripmeters; Digital Tachometer; Ambient Air Temperature; Fuel Range; Average Fuel Economy; Battery Voltage; Gear Position Display; |
Starter | Electric |
Color options | Thunder Black Smoke, Sagebrush Smoke, White Smoke |
