Honda CB1100 EX - 2017 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

CategoryClassic
Year2017
ModelHonda CB1100 EX



Engine and Transmission Specifications

Greenhouse gases139.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption6.00 litres/100 km (16.7 km/l or 39.20 mpg)
ClutchMulti-plate wet clutch
Transmission type,final driveChain
Gearbox6-speed
Cooling systemOil & air
IgnitionDigital transistorized with electronic advance
Fuel controlDouble Overhead Cams/Twin Cam (DOHC)
Fuel systemInjection. PGM-FI electronic fuel injection
Bore x Stroke73.5 x 67.2 mm (2.9 x 2.6 inches)
Compression9.5:1
Torque91.00 Nm (9.3 kgf-m or 67.1 ft.lbs) @ 5000 Revolutions">RPM
Power88.51 Horsepower">HP (64.6 Kilowatt">kW)) @ 7500 Revolutions">RPM
Engine typeIn-line four, four-stroke
Capacity:1140.00 ccm (69.56 cubic inches)



Brakes, suspension, Frame and wheels

WheelsWire spoked
Rear brakes diameter256 mm (10.1 inches)
Rear brakesSingle disc. Single-piston. ABS.
Front brakes diameter296 mm (11.7 inches)
Front brakesDouble disc. Floating discs. Four-piston calipers. ABS.
Rear tyre140/70-18
Front tyre110/80-18
Rear SuspensionTwin shocks with adjustable spring preload
Front Suspension41mm conventional fork with adjustable spring preload
Trail114 mm (4.5 inches)
Rake (fork angle)27.0°
Frame typeDouble steel cradle

Physical measures and capacities

Oil capacity4.90 litres (0.32 quarts)
Fuel capacity17.50 litres (4.62 gallons)
Wheelbase1,490 mm (58.7 inches)
Ground clearance135 mm (5.3 inches)
Overall width834 mm (32.8 inches)
Overall length2,195 mm (86.4 inches)
Overall height1,130 mm (44.5 inches)
Seat height795 mm (31.3 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc260.0 kg (573.2 pounds)

Other specs

Electrical11.2Ah battery.
InstrumentsFuel gauge, instant fuel consumption, remaining range, clock, new gear position indicator
StarterElectric
Color optionsBlack, white, red
