Harley-Davidson XL 1200N Sportster 1200 Nightster - 2010 Specifications and Reviews

2010

2009

Harley-Davidson XL 1200N Sportster 1200 Nightster 2010 18322 Thumb

General information
Category	Custom / cruiser
Year	2010
Model	Harley-Davidson XL 1200N Sportster 1200 Nightster

Engine and Transmission Specifications
Exhaust system	Chrome, staggered exhaust with dual mufflers
Clutch	9-plate, wet
Transmission type,final drive	Belt
Gearbox	5-speed
Cooling system	Air
Lubrication system	Dry sump
Fuel control	OHV
Fuel system	Injection. Electronic Sequential Port Fuel Injection
Valves per cylinder	2
Bore x stroke	88.9 x 96.8 mm (3.5 x 3.8 inches)
Compression	10.0:1
Torque	98.00 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 3200
Engine type	V2, four-stroke
Capacity:	1202.00 ccm (73.35 cubic inches)
Brakes, suspension, Frame and wheels
Rear brakes diameter	292 mm (11.5 inches)
Rear brakes	Single disc. Single piston
Front brakes diameter	292 mm (11.5 inches)
Front brakes	Single disc. Dual piston
Rear tyre dimensions	150/80-16
Front tyre dimensions	100/90-19
Rear suspension travel	92 mm (3.6 inches)
Rear suspension	Coil-over shocks, preload dual adjustment
Front suspension travel	92 mm (3.6 inches)
Front suspension	39mm
Trail	117 mm (4.6 inches)
Rake (fork angle)	30.0°
Frame type	Mild steel tubular frame; circular sections; cast junctions

Physical measures and capacities
Fuel capacity	12.50 litres (3.30 gallons)
Wheelbase	1,510 mm (59.4 inches)
Ground clearance	130 mm (5.1 inches)
Overall length	2,245 mm (88.4 inches)
Seat height	725 mm (28.5 inches) If adjustable, lowest setting.
Dry weight	251.0 kg (553.4 pounds)
Other specs
Color options	Vivid Black, Black Ice Denim, Brilliant Silver Denim/Black Denim, Scarlet Red/Vivid Black
Starter	Electric
