Harley-Davidson Road King Classic - 2018 Specifications and Reviews
General information | |
Category | Touring |
Year | 2018 |
Model | Harley-Davidson Road King Classic |
| |
Engine and Transmission Specifications | |
Exhaust system | Chrome, 2-1-2 dual exhaust with tapered mufflers |
Greenhouse gases | 113.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
Fuel consumption | 4.90 litres/100 km (20.4 km/l or 48.00 mpg) |
Driveline | Chain, 34/46 ratio primary drive |
Clutch | Multi-plate with diaphragm spring in oil bath |
Transmission type,final drive | Belt |
Gearbox | 6-speed |
Cooling system | Air |
Lubrication system | Dry sump |
Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
Fuel system | Injection. Electronic Sequential Port Fuel Injection |
Bore x Stroke | 100.0 x 111.1 mm (3.9 x 4.4 inches) |
Compression | 10.0:1 |
Torque | 150.00 Nm (15.3 kgf-m or 110.6 ft.lbs) @ 3200 Revolutions">RPM |
Power | 89.00 Horsepower">HP (65.0 Kilowatt">kW)) @ 5450 Revolutions">RPM |
Engine details | Milwaukee-Eight® 107, Integrated Oil-Cooler |
Engine type | V2, four-stroke |
Capacity: | 1687.97 ccm (103.00 cubic inches) |
| |
Brakes, suspension, Frame and wheels | |
Rear brakes | Single disc. Optional ABS. 4-piston |
Front brakes | Double disc. Optional ABS. 4-piston |
Rear tyre | 180/65-B16 |
Front tyre | MT90-B16 |
Rear Suspension | Twin shocks |
Front Suspension | Telescopic fork |
Trail | 170 mm (6.7 inches) |
Rake (fork angle) | 26.0° |
Physical measures and capacities | |
Oil capacity | 3.80 litres (0.25 quarts) |
Fuel capacity | 22.71 litres (6.00 gallons) |
Wheelbase | 1,625 mm (64.0 inches) |
Ground clearance | 125 mm (4.9 inches) |
Overall length | 2,420 mm (95.3 inches) |
Seat height | 715 mm (28.1 inches) If adjustable, lowest setting. |
Power/weight ratio | 0.2459 HP/kg |
Weight incl. oil, gas, etc | 376.0 kg (828.9 pounds) |
Dry weight | 362.0 kg (798.1 pounds) |
Other specs | |
Comments | Windshield. |
Carrying capacity | Saddle bags |
Light | High beam, running lights, front fender running lights, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional) |
Instruments | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-speed indicator light |
Starter | Electric |
Color options | Vivid Black, Bonneville Salt Pearl, Silver Fortune/Sumatra Brown, Twisted Cherry/Silver Fortune, Olive Gold/Black Tempest |
