Harley-Davidson FXCWC Softail Rocker C - 2010 Specifications and Reviews
General information | |
| Category | Custom / cruiser |
| Year | 2010 |
| Model | Harley-Davidson FXCWC Softail Rocker C |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, staggered shorty exhaust with dual mufflers |
| Clutch | 9-plate, wet |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel control | OHV |
| Fuel system | Injection. ESPFI |
| Valves per cylinder | 2 |
| Bore x stroke | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
| Compression | 9.2:1 |
| Torque | 121.00 Nm (12.3 kgf-m or 89.2 ft.lbs) @ 3250 |
| Engine type | V2, four-stroke |
| Capacity: | 1584.00 ccm (96.66 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc. 2-piston |
| Front brakes diameter | 292 mm (11.5 inches) |
| Front brakes | Single disc. 4-piston |
| Rear tyre dimensions | 240/40-R18 |
| Front tyre dimensions | 90/90-R19 |
| Rear suspension travel | 79 mm (3.1 inches) |
| Rear suspension | Hidden, horizontal-mounted, coil-over |
| Front suspension travel | 127 mm (5.0 inches) |
| Front suspension | 49mm telescopic |
| Trail | 157 mm (6.2 inches) |
| Rake (fork angle) | 36.0° |
| Frame type | Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded |
| | |
Physical measures and capacities | |
| Oil capacity | 3.10 litres (0.20 quarts) |
| Fuel capacity | 18.90 litres (4.99 gallons) |
| Wheelbase | 1,760 mm (69.3 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,415 mm (95.1 inches) |
| Seat height | 700 mm (27.6 inches) If adjustable, lowest setting. |
| Dry weight | 307.0 kg (676.8 pounds) |
Other specs | |
| Color options | Vivid Black Deluxe, Flame Blue Pearl Deluxe, Black Denim Deluxe, Red Hot Sunglo Deluxe |
| Starter | Electric |
