Harley-Davidson FLSTSE3 CVO Softail Convertible - 2012 Specifications and Reviews
2012
General information | |
| Category | Custom / cruiser |
| Year | 2012 |
| Model | Harley-Davidson FLSTSE3 CVO Softail Convertible |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, shorty-dual exhaust with chrome mufflers and muffler shields |
| Greenhouse gases | 121.3 CO |
| Fuel consumption | 5.23 litres/100 km (19.1 km/l or 44.98 mpg) |
| Driveline | Primary drive chain, 34/46 ratio. Final Drive Belt, 32/68 ratio |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Pressurized, dry-sump with oil cooler |
| Fuel control | DOHC |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Valves per cylinder | 2 |
| Bore x stroke | 101.6 x 111.3 mm (4.0 x 4.4 inches) |
| Compression | 9.2:1 |
| Torque | 142.38 Nm (14.5 kgf-m or 105.0 ft.lbs) @ 2750 |
| Engine details | Air-cooled, Twin Cam 110B |
| Engine type | V2, four-stroke |
| Capacity: | 1802.69 ccm (110.00 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Mirror Chrome Stinger Custom Wheels |
| Rear brakes diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc. 4-piston caliper. ABS. |
| Front brakes diameter | 292 mm (11.5 inches) |
| Front brakes | Single disc. 4-piston calipers. ABS. |
| Rear tyre dimensions | 200/50-R18 |
| Front tyre dimensions | 130/70-R18 |
| Rear suspension travel | 51 mm (2.0 inches) |
| Rear suspension | Hidden, horizontal-mounted, coil-over |
| Front suspension travel | 117 mm (4.6 inches) |
| Front suspension | 41.3 mm telescopic, chrome upper fork-slider covers |
| Trail | 147 mm (5.8 inches) |
| Rake (fork angle) | 32.0° |
Physical measures and capacities | |
| Oil capacity | 2.80 litres (0.18 quarts) |
| Fuel capacity | 18.93 litres (5.00 gallons) |
| Wheelbase | 1,631 mm (64.2 inches) |
| Ground clearance | 109 mm (4.3 inches) |
| Overall length | 2,410 mm (94.9 inches) |
| Seat height | 620 mm (24.4 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 357.4 kg (788.0 pounds) |
| Dry weight | 345.2 kg (761.0 pounds) |
| | |
Other specs | |
| Comments | French brand. |
| Wheelbase | 1,285 mm (50.6 inches) |
| Overall width | 685 mm (27.0 inches) |
| Overall height | 1,150 mm (45.3 inches) |
| Power/weight ratio | 0.0472 HP/kg |
| Rear tyre | 3.00-12 |
| Front tyre | 2.50-12 |
| Ignition | CDI |
| Torque | 4.00 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5500 Revolutions">RPM |
| Power | 4.15 Horsepower">HP (3.0 Kilowatt">kW)) @ 8000 Revolutions">RPM |
| Capacity: | 49.20 ccm (3.00 cubic inches) |
| Model | Goes G 55 R Sport |
| Color options | Crimson Red Sunglo with Scarlet Crystal graphics, Abyss Blue with Catacomb graphics, Satin Pewter with Catacomb graphics |
| Factory warranty | 2 years, unlimited mileage. |
| Seat | Custom leather seat, removable passenger pillion, and detachable stylized passenger upright and backrest pad with distressed brown leather (satin pewter only) or reptile inserts |
| Electrical | Sealed, maintenance-free battery, |
| Light | 55-watt low beam, 60-watt high beam |
| Instruments | Digital speedometer and analog tachometer. Time of day clock on odometer, dual tripmeter, engine diagnostics readout, LED indicator lights |
| Starter | Electric |
