Harley-Davidson FLSTF Softail Fat Boy - 2010 Specifications and Reviews
General information | |
| Category | Custom / cruiser |
| Year | 2010 |
| Model | Harley-Davidson FLSTF Softail Fat Boy |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Chrome, over/under shotgun exhaust with dual mufflers |
| Clutch | 9-plate, wet |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel control | OHV |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Bore x stroke | 95.3 x 111.1 mm (3.8 x 4.4 inches) |
| Compression | 9.2:1 |
| Torque | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 3500 |
| Engine type | V2, four-stroke |
| Capacity: | 1584.00 ccm (96.66 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter | 292 mm (11.5 inches) |
| Rear brakes | Single disc. 2-piston |
| Front brakes diameter | 292 mm (11.5 inches) |
| Front brakes | Single disc. 4-piston |
| Rear tyre dimensions | 200/55-R17 |
| Rear suspension travel | 91 mm (3.6 inches) |
| Rear suspension | Hidden, horizontal-mounted, coil-over |
| Front suspension travel | 97 mm (3.8 inches) |
| Front suspension | 41.3mm telescopic, beer can covers |
| Trail | 147 mm (5.8 inches) |
| Rake (fork angle) | 31.0° |
| Frame type | Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded |
| | |
Physical measures and capacities | |
| Oil capacity | 3.10 litres (0.20 quarts) |
| Fuel capacity | 19.70 litres (5.20 gallons) |
| Wheelbase | 1,635 mm (64.4 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,396 mm (94.3 inches) |
| Seat height | 690 mm (27.2 inches) If adjustable, lowest setting. |
| Dry weight | 313.0 kg (690.0 pounds) |
Other specs | |
| Color options | Vivid Black, Scarlet Red, Brilliant Silver Pearl, Flame Blue Pearl, Black Ice Pearl |
| Starter | Electric |
