Harley-Davidson FLHTK Electra Glide Ultra Limited - 2011 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2011 |
| Model | Harley-Davidson FLHTK Electra Glide Ultra Limited |
Engine and Transmission Specifications | |
| Exhaust system | 2-1-2 chrome exhaust with dual mufflers and taper end caps |
| Driveline | Primary Drive: Chain, 34/46 ratio. Final Drive: 32/68 ratio |
| Clutch | 9-plate, wet |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Lubrication system | Pressurized, dry-sump with oil cooler |
| Fuel control | DOHC |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection |
| Valves per cylinder | 2 |
| Bore x stroke | 98.4 x 111.1 mm (3.9 x 4.4 inches) |
| Compression | 9.6:1 |
| Torque | 138.00 Nm (14.1 kgf-m or 101.8 ft.lbs) @ 3500 |
| Engine details | Air-cooled, Twin Cam 103. Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder. |
| Engine type | V2, four-stroke |
| Capacity: | 1690.00 ccm (103.12 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Contrast Chrome, 28-spoke Cast Aluminum |
| Rear brakes diameter | 300 mm (11.8 inches) |
| Rear brakes | Single disc. 4-piston fixed caliper. Optional ABS. |
| Front brakes diameter | 300 mm (11.8 inches) |
| Front brakes | Double disc. 4-piston fixed caliper. Optional ABS. |
| Rear tyre dimensions | 180/65-B16 |
| Front tyre dimensions | 130/80-B17 |
| Rear suspension travel | 76 mm (3.0 inches) |
| Rear suspension | Air-adjustable |
| Front suspension travel | 117 mm (4.6 inches) |
| Front suspension | 41.3mm telescopic, triple circuit damping |
| Trail | 170 mm (6.7 inches) |
| Rake (fork angle) | 26.0° |
| Frame type | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded. |
Physical measures and capacities | |
| Oil capacity | 3.80 litres (0.25 quarts) |
| Fuel capacity | 22.70 litres (6.00 gallons) |
| Wheelbase | 1,635 mm (64.4 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Overall length | 2,525 mm (99.4 inches) |
| Seat height | 739 mm (29.1 inches) If adjustable, lowest setting. |
| Dry weight | 389.2 kg (858.0 pounds) |
Other specs | |
| Carrying capacity | Front and rear rack |
| Wheelbase | 1,490 mm (58.7 inches) |
| Overall width | 1,180 mm (46.5 inches) |
| Overall height | 1,230 mm (48.4 inches) |
| Power/weight ratio | 0.1114 HP/kg |
| Rear tyre | 25/10-12 |
| Front tyre | 25/8-12 |
| Rear Suspension | Gas shocks with pre-load adjustment |
| Front Suspension | Independent double A-arm |
| Ignition | CDI |
| Bore x Stroke | 96.0 x 82.0 mm (3.8 x 3.2 inches) |
| Compression | 10.2:1 |
| Torque | 46.90 Nm (4.8 kgf-m or 34.6 ft.lbs) |
| Power | 37.55 Horsepower">HP (27.4 Kilowatt">kW)) |
| Capacity: | 594.00 ccm (36.25 cubic inches) |
| Model | Goes G 625i Max |
| Color options | Vivid Black, Cherry Red Sunglo/Merlot Sunglo, Cool Blue Pearl/Vivid Black, Dark Candy Root Beer/Light Candy, Root Beer, Psychedelic Purple/Vivid Black, Apple Green/Vivid Black |
| Factory warranty | 24 months. |
| Electrical | Sealed, maintenance-free, 12V, 28-amp/hour, 370 cca battry. Charging: Three-phase, 50-amp system |
| Instruments | Fairing-mounted electronic speedometer with odometer; time-of-day clock on CD player/stereo; dual trip meter; low fuel indicator light and mileage countdown feature; low oil pressure indicator light; engine diagnostics readout; LED indicator lights; 6-spe |
| Starter | Electric |
