Harley-Davidson Dyna Switchback - 2013 Specifications and Reviews
General information | |
| Category | Touring |
| Year | 2013 |
| Model | Harley-Davidson Dyna Switchback |
| | |
Engine and Transmission Specifications | |
| Exhaust system | 2-into-1 chrome exhaust with straight-cut muffler |
| Greenhouse gases | 129.9 CO |
| Fuel consumption | 5.60 litres/100 km (17.9 km/l or 42.00 mpg) |
| Driveline | Primary chain, 34/46 ratio |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Cooling system | Air |
| Fuel system | Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
| Bore x stroke | 98.4 x 111.3 mm (3.9 x 4.4 inches) |
| Compression | 9.6:1 |
| Torque | 135.60 Nm (13.8 kgf-m or 100.0 ft.lbs) @ 3500 |
| Engine details | Air-cooled, Twin Cam 103™ |
| Engine type | V2, four-stroke |
| Capacity: | 1687.97 ccm (103.00 cubic inches) |
| | |
Brakes, suspension, Frame and wheels | |
| Wheels | Black, 5-Spoke Cast Aluminum |
| Rear brakes | Single disc. 2-piston torque-free floating |
| Front brakes | Double disc. 4-piston fixed |
| Rear tyre dimensions | 160/70-B17 |
| Front tyre dimensions | 130/70-B18 |
| Trail | 147 mm (5.8 inches) |
| Rake (fork angle) | 29.9° |
Physical measures and capacities | |
| Oil capacity | 2.80 litres (0.18 quarts) |
| Fuel capacity | 17.79 litres (4.70 gallons) |
| Wheelbase | 1,595 mm (62.8 inches) |
| Ground clearance | 109 mm (4.3 inches) |
| Overall length | 2,360 mm (92.9 inches) |
| Seat height | 663 mm (26.1 inches) If adjustable, lowest setting. |
| Weight incl. oil, gas, etc | 325.7 kg (718.0 pounds) |
| Dry weight | 315.7 kg (696.0 pounds) |
Other specs | |
| Comments | Amphibian. |
| Wheelbase | 1,800 mm (70.9 inches) |
| Overall width | 1,600 mm (63.0 inches) |
| Overall height | 1,400 mm (55.1 inches) |
| Rear Suspension | Independent coil springs and hydraulic dampers |
| Front Suspension | Independent coil springs and hydraulic dampers |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Valves per cylinder | 4 |
| Top speed | 45.0 km/h (28.0 mph) |
| Capacity: | 1300.00 ccm (79.33 cubic inches) |
| Model | Gibbs Quadski |
| Color options | Ember Red Sunglo, Vivid Black, Big Blue Pearl |
| Light | High beam, neutral, low oil pressure, engine diagnostics, turn signals, low fuel warning, ABS (optional), low battery, body controller diagnostics |
| Instruments | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light |
| Starter | Electric |
