Ducati Diavel 1260 S - 2022 Specifications and Reviews
General information | |
Category | Allround |
Year | 2022 |
Model | Ducati Diavel 1260 S |
| |
Engine and Transmission Specifications | |
Exhaust system | Stainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes |
Emission details | Euro 5 |
Greenhouse gases | 127.6 CO2 g/km. (CO2 - Carbon dioxide emission) |
Fuel consumption | 5.50 litres/100 km (18.2 km/l or 42.77 mpg) |
Driveline | Chain |
Clutch | Slipper and self-servo wet multiplate clutch with hydraulic control |
Transmission type | Chain (final drive) |
Gearbox | 6-speed |
Cooling system | Liquid |
Ignition | Dual Spark |
Fuel control | Desmodromic valve control |
Fuel system | Injection. Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm |
Valves per Cylinder | 4 |
Bore x Stroke | 106.0 x 71.5 mm (4.2 x 2.8 inches) |
Compression | 13.0:1 |
Torque | 129.0 Nm (13.2 kgf-m or 95.2 ft.lbs) @ 7500 Revolutions">RPM |
Power | 162.0 Horsepower">HP (118.2 Kilowatt">kW)) @ 9500 Revolutions">RPM |
Engine details | Testastretta DVT L-twin |
Engine type | V2, four-stroke |
Capacity: | 1262.0 ccm (77.01 cubic inches) |
Brakes, suspension, Frame and wheels | |
Seat | Dual seat |
Wheels | Light alloy casted and machined. Pirelli Diablo Rosso III tires. |
Rear brakes | Single disc. ABS. Two-piston calipers. |
Diameter | 320 mm (12.6 inches) |
Front brakes | Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted. |
Rear tire | 240/45-ZR17 |
Front tire | 120/70-ZR17 |
Rear wheel travel | 130 mm (5.1 inches) |
Rear Suspension | Öhlins fully adjustable monoshock, Aluminium casted single-sided swingarm. |
Front wheel travel | 120 mm (4.7 inches) |
Front Suspension | Ø 48 mm Öhlins adjustable usd fork, TiN treatment. |
Trail | 120 mm (4.7 inches) |
Rake (fork angle) | 27.0° |
Frame type | Tubular steel Trellis |
Physical measures and capacities | |
Fuel capacity | 17.00 litres (4.49 US gallons) |
Wheelbase | 1600 mm (63.0 inches) |
Overall length | 2200 mm (86.6 inches) |
Alternate seat height | 845 mm (33.3 inches) If adjustable, highest setting. |
Seat height | 780 mm (30.7 inches) If adjustable, lowest setting. |
Power/weight ratio | 0.7330 HP/kg |
Weight incl. oil, gas, etc | 247.0 kg (544.5 pounds) |
Dry weight | 221.0 kg (487.2 pounds) |
| |
Other specs | |
Comments | Bosch Cornering ABS Evo, Ducati Traction Control Evo DTC. Riding Modes, Power Modes. Ducati Wheelie Control Evo (DWC). |
Factory warranty | 2 years unlimited mileage |
Instruments | TFT colour display and dedicated warning light display |
Starter | Electric |
Color options | Black/steel/yellow, Total Black |
