Big Bear Choppers Athena 114 X-Wedge EFI - 2010 Specifications and Reviews
2010
General information | |
| Category | Custom / cruiser |
| Year | 2010 |
| Model | Big Bear Choppers Athena 114 X-Wedge EFI |
| | |
Engine and Transmission Specifications | |
| Exhaust system | Chrome Radius Tuned Exhaust |
| Transmission type,final drive | Belt |
| Gearbox | 6-speed |
| Lubrication system | S and S High volume oil pump |
| Fuel system | Injection. S and S Closed-Loop Electronic Fuel Injection |
| Bore x stroke | 104.8 x 108.0 mm (4.1 x 4.3 inches) |
| Torque | 153.22 Nm (15.6 kgf-m or 113.0 ft.lbs) |
| Power | 97.00 |
| Engine type | V2, four-stroke |
| Capacity: | 1868.24 ccm (114.00 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes | Single disc. BBC-PM 4-piston caliper BrakeDrive system |
| Front brakes | Single disc. PM. 4-piston calipers |
| Rear tyre dimensions | 300/80-18 |
| Front tyre dimensions | 90/80-21 |
| Rear suspension travel | 76 mm (3.0 inches) |
| Rear suspension | Progressive |
| Front suspension | BBC Smooth Mount Hidden Axle |
| Trail | 95 mm (3.8 inches) |
| Rake (fork angle) | 40.0° |
| Frame type | Softail type |
| | |
Physical measures and capacities | |
| Oil capacity | 4.70 litres (0.31 quarts) |
| Fuel capacity | 13.72 litres (3.62 gallons) |
| Wheelbase | 2,235 mm (88.0 inches) |
| Overall length | 2,921 mm (115.0 inches) |
| Seat height | 508 mm (20.0 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.3055 HP/kg |
| Dry weight | 317.5 kg (700.0 pounds) |
Other specs | |
| Color options | Gross Black, satin black, charcoal metallic, silver, black cherry, candy red, firecracker red, orange, electric blue. |
| Starter | Electric |
