BMW R 1200 GS Adventure - 2017 Specifications and Reviews
General information | |
| Category | Enduro / offroad |
| Year | 2017 |
| Model | BMW R 1200 GS Adventure |
| | |
Engine and Transmission Specifications | |
| Emission details | EU-4 |
| Clutch | Wet eight-disc clutch with anti-hopping function, hydraulically operated |
| Transmission type,final drive | Shaft drive (cardan) |
| Gearbox | 6-speed |
| Cooling system | Liquid |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Fuel system | Injection. Electronic intake pipe injection |
| Valves per cylinder | 4 |
| Bore x Stroke | 101.0 x 73.0 mm (4.0 x 2.9 inches) |
| Compression | 12.5:1 |
| Torque | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions">RPM |
| Power | 125.00 Horsepower">HP (91.2 Kilowatt">kW)) @ 7750 Revolutions">RPM |
| Engine type | Twin, four-stroke |
Brakes, suspension, Frame and wheels | |
| Wheels | Cross Spoke Wheels |
| Rear brakes diameter | 276 mm (10.9 inches) |
| Rear brakes | Single disc. ABS |
| Front brakes diameter | 305 mm (12.0 inches) |
| Front brakes | Double disc. ABS. Four-piston calipers. |
| Rear tyre | 170/60-R17 |
| Front tyre | 120/70-R19 |
| Rear wheel travel | 220 mm (8.7 inches) |
| Rear Suspension | BMW Motrrad EVO Paralever, rear |
| Front wheel travel | 210 mm (8.3 inches) |
| Front Suspension | BMW Motorrad Telelever, front, stanchion diameter 37 mm |
| Trail | 93 mm (3.6 inches) |
| Rake (fork angle) | 24.5° |
| Frame type | Two-section frame, front- and bolted on rear frame, load-bearing engine |
Physical measures and capacities | |
| Reserve fuel capacity | 4.00 litres (1.06 gallons) |
| Fuel capacity | 30.00 litres (7.93 gallons) |
| Wheelbase | 1,510 mm (59.4 inches) |
| Overall width | 980 mm (38.6 inches) |
| Overall length | 2,255 mm (88.8 inches) |
| Overall height | 1,450 mm (57.1 inches) |
| Seat height | 890 mm (35.0 inches) If adjustable, lowest setting. |
| Power/weight ratio | 0.5457 HP/kg |
| Weight incl. oil, gas, etc | 263.0 kg (579.8 pounds) |
| Dry weight | 229.1 kg (505.0 pounds) |
| | |
Other specs | |
| Comments | Windscreen. Switchable ABS. |
| Starter | Electric |
| Color options | Light White, Racing Red Matt |
