Triumph Tiger 1200 XCX - 2018 Specifications and Reviews

4.5 stars Average rating: 4.5 from 8 votes
.

General information

CategoryAllround
Year2018
ModelTriumph Tiger 1200 XCX

Engine and Transmission Specifications

Exhaust systemStainless steel 3 into 1 side mounted stainless steel silencer
Greenhouse gases113.7 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption4.90 litres/100 km (20.4 km/l or 48.00 mpg)
ClutchWet, multi-plate hydraulically operated, torque assist
Transmission type,final driveShaft drive (cardan)
Gearbox6-speed
Cooling systemLiquid
Fuel controlDouble Overhead Cams/Twin Cam (DOHC)
Fuel systemInjection
Valves per cylinder4
Bore x Stroke85.0 x 71.4 mm (3.3 x 2.8 inches)
Compression11.0:1
Torque122.00 Nm (12.4 kgf-m or 90.0 ft.lbs) @ 7600 Revolutions">RPM
Power139.00 Horsepower">HP (101.5 Kilowatt">kW)) @ 9300 Revolutions">RPM
Engine typeIn-line three, four-stroke



Brakes, suspension, Frame and wheels

WheelsCast aluminum alloy 10-spoke
Rear brakes diameter282 mm (11.1 inches)
Rear brakesSingle disc. Nissin 2-piston sliding caliper, switchable ABS
Front brakes diameter305 mm (12.0 inches)
Front brakesDouble disc. Floating discs, radially mounted monobloc Brembo calipers, 4-piston, switchable ABS.
Rear tyre170/60-R17
Front tyre120/70-R19
Rear wheel travel193 mm (7.6 inches)
Rear SuspensionWP monoshock, electronically adjustable semi active damping,
Front wheel travel190 mm (7.5 inches)
Front SuspensionWP 48 mm upside down forks, electronically adjustable damping,
Trail100 mm (3.9 inches)
Rake (fork angle)23.2°
Frame typeTubular steel trellis frame. Single-­sided, cast aluminium alloy swing arm with shaft drive.

Physical measures and capacities

Oil capacity4.00 litres (0.26 quarts)
Fuel capacity20.00 litres (5.28 gallons)
Wheelbase1,520 mm (59.8 inches)
Overall width885 mm (34.8 inches)
Overall length2,248 mm (88.5 inches)
Overall height1,470 mm (57.9 inches)
Alternate seat height855 mm (33.7 inches) If adjustable, highest setting.
Seat height835 mm (32.9 inches) If adjustable, lowest setting.
Power/weight ratio0.5744 HP/kg
Dry weight242.0 kg (533.5 pounds)

Other specs

CommentsWindscreen. Auxiliary lights. Engine protection bars. Hand guards. Sump guard. Advanced On Board computer. Cruise Control. Semi Active Suspension.
Factory warranty24 months unlimited mileage
InstrumentsLCD instrument pack with digital speedometer, analogue tachometer, gear position indicator, fuel gauge, range to empty, service indicator, clock, air temperature, frost warning, hazard warning lights, trip computer, Tyre pressure monitoring system
StarterElectric
Color optionsJet Black, Crystal White

Rider Reviews

Total comments: 1
64x64

MotorcycleDB Review

The 2018 Triumph Tiger 1200 XCX is a high-performance adventure motorcycle that offers a smooth and powerful ride. With its 1,215cc engine and advanced technology, this bike delivers excellent performance both on and off-road. The XCX model comes equipped with a range of features including six riding modes, heated seats and grips, and a semi-active suspension system that ensures a comfortable and controlled ride in all conditions. Whether you're tackling challenging terrain or cruising on the highway, the Tiger 1200 XCX provides a thrilling and capable riding experience. In addition to its impressive performance, the Triumph Tiger 1200 XCX boasts a stylish and rugged design that is sure to turn heads on the road. Its distinctive appearance, combined with a range of customization options, makes this bike a standout choice for adventure enthusiasts. With its powerful engine, advanced technology, and striking design, the 2018 Triumph Tiger 1200 XCX is a top contender in the adventure motorcycle market.
