Suzuki DR650SE - 2013 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Enduro / offroad
Year:2013
Model:Suzuki DR650SE


Engine and Transmission Specifications

Driveline:Chain, DID525V9, 110 links
Transmission type,final drive:Chain
Gearbox:5-speed
Cooling system:Air
Lubrication system:Wet sump
Ignition:Electronic ignition
Fuel control:OHC
Bore x stroke:100.0 x 82.0 mm (3.9 x 3.2 inches)
Engine type:Single cylinder, four-stroke
Capacity:644.00 ccm (39.30 cubic inches)

Brakes, suspension, Frame and wheels

Rear brakes:Expanding brake (drum brake)
Front brakes:Single disc
Rear tyre dimensions:120/90-M17
Front tyre dimensions:90/90-M
Rear suspension:Link type, coil spring, oil damped
Front suspension:Telescopic, coil spring, oil damped

Physical measures and capacities

Fuel capacity:12.87 litres (3.40 gallons)
Wheelbase:1,490 mm (58.7 inches)
Ground clearance:265 mm (10.4 inches)
Overall width:865 mm (34.1 inches)
Overall length:2,255 mm (88.8 inches)
Seat height:885 mm (34.8 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:166.0 kg (366.0 pounds)


Other specs

Comments:Chinese ATV.
Wheelbase:1,280 mm (50.4 inches)
Dry weight:210.0 kg (463.0 pounds)
Rear brakes diameter:200 mm (7.9 inches)
Front brakes diameter:160 mm (6.3 inches)
Rear tyre:20/19-9
Front tyre:21/7-10
Rear Suspension:Soli axle, fully adjustable monoshock w/remote reservoir 10.6 inch travel. Linkage type. Steel swingarm.
Front wheel travel:231 mm (9.1 inches)
Front Suspension:Independent. Double wishbone, Fully adjust shocks with remote reservoirs, preload, compression and
Frame type:Steel
Fuel system:Carburettor. 3 KunFu CV Type
Bore x Stroke:56.0 x 53.0 mm (2.2 x 2.1 inches)
Capacity:392.00 ccm (23.92 cubic inches)
Color options:Solid Iron Gray
Factory warranty:12 month unlimited mileage limited warranty.
Starter:Electric
