Saxon Henchman (2009)

Not Rated stars Average rating: Not Rated from 0 votes
.



General information

Model:Saxon Henchman
Year:2009
Category:Custom / cruiser


Engine and transmission

Displacement:1573.00 ccm (95.98 cubic inches)
Engine type:V2
Stroke:4
Compression:10.1:1
Bore x stroke:94.0 x 116.8 mm (3.7 x 4.6 inches)
Fuel system:Carburettor. S and S Super E Carburator
Fuel control:OHV
Starter:Electric
Gearbox:6-speed
Transmission typefinal drive:Chain


Physical measures and capacities

Dry weight:283.5 kg (625.0 pounds)
Seat height:660 mm (26.0 inches) If adjustable, lowest setting.



Saxon Henchman dimensions and frame

Frame type:Stretch 0 In Downtube 1-3/4 In Backbon
Rake (fork angle):35.0°
Front suspension:Springer or 41mm Telescopic
Rear suspension:Rigid
Front tyre dimensions:2.15-21
Rear tyre dimensions:200-16
Front brakes:Single disc. Bremo 4-piston calipers
Rear brakes:Single disc. Bremo 2- piston calipers


Speed and acceleration

Fuel capacity:11.35 litres (3.00 gallons)
Fuel consumption pr. 10 km (6.2 miles):67.20 litres (17.75 gallons)
Oil capacity:3.30 litres (0.22 quarts)
