Kawasaki Vulcan 1600 Nomad (2005)

Not Rated stars
Average rating: Not Rated
from 0 votes.



General information

Model:Kawasaki Vulcan 1600 Nomad
Year:2005
Category:Custom / cruiser


Engine and transmission

Displacement:1550.00 ccm (94.58 cubic inches)
Engine type:V2
Stroke:4
Compression:9.0:1
Bore x stroke:102.0 x 95.0 mm (4.0 x 3.7 inches)
Fuel system:Injection. Digital fuel injection with (2) 36mm throttle bodies
Valves per cylinder:4
Fuel control:SOHC
Ignition:Digital
Starter:Electric
Cooling system:Liquid
Gearbox:5-speed
Transmission typefinal drive:Shaft drive (cardan)



Physical measures and capacities

Seat height:706 mm (27.8 inches) If adjustable, lowest setting.
Ground clearance:135 mm (5.3 inches)
Wheelbase:1,684 mm (66.3 inches)



Kawasaki Vulcan 1600 Nomad dimensions and frame

Frame type:High-tensile steel, double cradle
Rake (fork angle):32.0°
Front suspension:43mm hydraulic fork
Rear suspension:Dual hydraulic shocks
Front tyre dimensions:150/80-16
Rear tyre dimensions:170/70-16
Front brakes:Double disc
Front brakes diameter:300 mm (11.8 inches)
Rear brakes:Single disc
Rear brakes diameter:300 mm (11.8 inches)


Speed and acceleration

Fuel capacity:20.06 litres (5.30 gallons)
Color options:Blue, Black
