Kawasaki KLR 250 (2001)

Not Rated stars
Average rating: Not Rated
from 0 votes.



General information

Model:Kawasaki KLR 250
Year:2001
Category:Enduro / offroad


Engine and transmission

Displacement:249.00 ccm (15.19 cubic inches)
Engine type:Single cylinder
Stroke:4
Compression:11.0:1
Bore x stroke:74.0 x 58.0 mm (2.9 x 2.3 inches)
Fuel system:Carburettor. Keihin CVK34
Valves per cylinder:4
Lubrication system:Wet sump
Cooling system:Liquid
Gearbox:6-speed
Transmission typefinal drive:Chain
Clutch:Wet multi-disc manual


Physical measures and capacities

Dry weight:117.0 kg (257.9 pounds)
Seat height:855 mm (33.7 inches) If adjustable, lowest setting.
Ground clearance:270 mm (10.6 inches)
Wheelbase:1,415 mm (55.7 inches)


Kawasaki KLR 250 dimensions and frame

Frame type:steel
Front suspension travel:230 mm (9.1 inches)
Rear suspension travel:230 mm (9.1 inches)
Front brakes:Single disc
Front brakes diameter:212 mm (8.3 inches)
Rear brakes:Expanding brake (drum brake)
Rear brakes diameter:120 mm (4.7 inches)
Exhaust system:single steel



Speed and acceleration

Fuel capacity:11.00 litres (2.91 gallons)
