Kawasaki Concours 14 - 2009 Specifications and Reviews
General information | |
| Category: | Sport touring |
| Year: | 2009 |
| Model: | Kawasaki Concours 14 |
Engine and Transmission Specifications | |
| Transmission type,final drive: | Shaft drive (cardan) |
| Gearbox: | 6-speed |
| Cooling system: | Liquid |
| Ignition: | TCBI with Digital Advance |
| Fuel control: | DOHC |
| Fuel system: | Injection. Digital |
| Valves per cylinder: | 4 |
| Bore x stroke: | 84.0 x 61.0 mm (3.3 x 2.4 inches) |
| Compression: | 10.7:1 |
| Torque: | 136.00 Nm (13.9 kgf-m or 100.3 ft.lbs) @ 6200 |
| Engine type: | In-line four, four-stroke |
| Capacity: | 1352.00 ccm (82.50 cubic inches) |
Brakes, suspension, Frame and wheels | |
| Rear brakes diameter: | 270 mm (10.6 inches) |
| Rear brakes: | Single disc |
| Front brakes diameter: | 310 mm (12.2 inches) |
| Front brakes: | Double disc |
| Rear tyre dimensions: | 190/50-ZR17 |
| Front tyre dimensions: | 120/70-ZR17 |
| Rear suspension: | Tetra-Lever with stepless rebound damping adjustment and remote spring preload adjuster / 5.4 in. |
| Front suspension: | 43mm inverted, telescopic fork with adjustable rebound damping and spring preload / 4.4 in. |
| Trail: | 112 mm (4.4 inches) |
| Rake (fork angle): | 26.1° |
Physical measures and capacities | |
| Fuel capacity: | 21.95 litres (5.80 gallons) |
| Wheelbase: | 1,519 mm (59.8 inches) |
| Overall width: | 780 mm (30.7 inches) |
| Overall length: | 2,271 mm (89.4 inches) |
| Seat height: | 815 mm (32.1 inches) If adjustable, lowest setting. |
| Dry weight: | 304.0 kg (670.3 pounds) |
Other specs | |
| Color options: | Metallic Diablo Black/Flat Super Black, Candy Diamond Red/Flat Super Black |
