KTM 690 Duke - 2008 Specifications and Reviews

5 stars Average rating: 5 from 1 votes
.

General information

Category:Naked bike
Year:2008
Model:KTM 690 Duke


Engine and Transmission Specifications

Exhaust system:Stainless steel underfloor silencer with integrated catalytic converter
Clutch:APTC Wet multi-disc clutch, operated hydraulically
Gearbox:6-speed
Cooling system:Liquid
Lubrication system:Pressure lubrication with 2 Eaton pumps
Ignition:2 X keihin
Fuel control:OHC
Fuel system:Carburettor
Valves per cylinder:4
Bore x stroke:102.0 x 80.0 mm (4.0 x 3.1 inches)
Compression:11.8:1
Torque:67.00 Nm (6.8 kgf-m or 49.4 ft.lbs) @ 5500
Power:64.36
Engine type:Single cylinder, four-stroke
Capacity:654.00 ccm (39.91 cubic inches)


Brakes, suspension, Frame and wheels

Rear brakes diameter:220 mm (8.7 inches)
Rear brakes:Single disc
Front brakes diameter:320 mm (12.6 inches)
Front brakes:Single disc
Rear tyre dimensions:160/60-17
Front tyre dimensions:120/70-17
Rear suspension travel:210 mm (8.3 inches)
Rear suspension:WP monoshock
Front suspension travel:200 mm (7.9 inches)
Front suspension:WP USD
Frame type:Chromium-molybdenum trellis frame, powder-coated

Physical measures and capacities

Fuel capacity:13.50 litres (3.57 gallons)
Wheelbase:1,472 mm (58.0 inches)
Ground clearance:155 mm (6.1 inches)
Seat height:865 mm (34.1 inches) If adjustable, lowest setting.
Power/weight ratio:0.4334 HP/kg
Dry weight:148.5 kg (327.4 pounds)

Other specs

Starter:Electric
