Harley-Davidson XL883L Sportster SuperLow (2012) Motorcycle manufacturer Harley-Davidson - Click for details


2012 Harley-Davidson XL883L Sportster SuperLow

Add/Upload more pictures of this motorcycle



2012 Harley-Davidson XL883L Sportster SuperLow specifications

Other specs
Color options:Vivid Black, Ember Red Sunglo, Midnight Pearl/Cool Blue Pearl, Birch White/Sunburst Red
Factory warranty:24 months, unlimited mileage.
Seat:Solo seat with deep bucket shape
Electrical:Sealed lead acid battery, maintenance-free, 12V, 12 amp/hour, 200 cca.
Light:High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
Starter:Electric
Instruments:Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
Physical measures and capacities
Oil capacity:2.60 litres (0.17 quarts)
Fuel capacity:17.03 litres (4.50 gallons)
Wheelbase:1,506 mm (59.3 inches)
Overall length:2,187 mm (86.1 inches)
Ground clearance:97 mm (3.8 inches)
Seat height:648 mm (25.5 inches) If adjustable, lowest setting.
Weight incl. oil, gas, etc:255.4 kg (563.0 pounds)
Brakes, suspension, Frame and wheels
Wheels:Black, Split 5-Spoke with Machined Rim
Physical measures and capacities
Dry weight:243.1 kg (536.0 pounds)
Brakes, suspension, Frame and wheels
Rear brakes:Single disc. Single-piston
Rear brakes diameter:260 mm (10.2 inches)
Front brakes diameter:292 mm (11.5 inches)
Front brakes:Single disc. Dual-piston
Front tyre dimensions:120/70-ZR18
Rear tyre dimensions:150/60-ZR17
Rear suspension:Mild steel, rectangular tube section, stamped junctions, MIG welded swing-arm. Coil-over; preload dual-adjustable shocks.
Trail:145 mm (5.7 inches)
Front suspension:39 mm Showa
Rake (fork angle):31.1°
Frame type:Mild steel, tubular frame; circular sections; cast junctions
Engine and transmission
Exhaust system:Chrome, staggered, shorty exhaust with dual mufflers
Greenhouse gases:107.0 CO
Fuel consumption:4.61 litres/100 km (21.7 km/l or 51.02 mpg)
Driveline:Chain primary drive, 57/34 ratio
Clutch:Multi-plate with diaphragm spring in oil bath
Transmission type,final drive:Belt
Gearbox:5-speed
Lubrication system:Dry-sump
Cooling system:Air
Bore x stroke:76.2 x 96.8 mm (3.0 x 3.8 inches)
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Compression:8.9:1
Torque:74.58 Nm (7.6 kgf-m or 55.0 ft.lbs) @ 3500
Engine details:Air-cooled, Evolution. Silver, powder-coated engine with polished covers.
Engine type:V2, four-stroke
Displacement:883.32 ccm (53.90 cubic inches)
General information
Year:2012
Category:Custom / cruiser
Model:Harley-Davidson XL883L Sportster SuperLow
