Harley-Davidson Ultra Limited - 2018 Specifications and Reviews

Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Touring
Year:2018
Model:Harley-Davidson Ultra Limited

Engine and Transmission Specifications

Exhaust system:Chrome, 2-1-2 dual exhaust with tapered mufflers
Greenhouse gases:141.5 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption:6.10 litres/100 km (16.4 km/l or 38.56 mpg)
Driveline:Chain, 34/46 ratio primary drive
Clutch:Multi-plate with diaphragm spring in oil bath
Transmission type,final drive:Belt
Gearbox:6-speed
Cooling system:Oil & air
Lubrication system:Dry sump
Fuel control:Double Overhead Cams/Twin Cam (DOHC)
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Bore x Stroke:100.0 x 111.1 mm (3.9 x 4.4 inches)
Compression:10.0:1
Torque:153.00 Nm (15.6 kgf-m or 112.9 ft.lbs) @ 3250 Revolutions">RPM
Power:90.00 Horsepower">HP (65.7 Kilowatt">kW)) @ 5450 Revolutions">RPM
Engine details:Twin-Cooled™ Milwaukee-Eight™ 107
Engine type:V2, four-stroke


Brakes, suspension, Frame and wheels

Wheels:Contrast Chrome Impeller Cast Aluminum
Rear brakes:Single disc. ABS. 4-piston
Front brakes:Double disc. ABS. 4-piston
Rear tyre:180/65-B16
Front tyre:130/80-B17
Rear Suspension:Twin shocks
Front Suspension:Telescopic fork
Trail:170 mm (6.7 inches)
Rake (fork angle):26.0°


Physical measures and capacities

Oil capacity:4.70 litres (0.31 quarts)
Fuel capacity:22.71 litres (6.00 gallons)
Wheelbase:1,625 mm (64.0 inches)
Ground clearance:135 mm (5.3 inches)
Overall length:2,600 mm (102.4 inches)
Seat height:740 mm (29.1 inches) If adjustable, lowest setting.
Power/weight ratio:0.2261 HP/kg
Weight incl. oil, gas, etc:413.0 kg (910.5 pounds)
Dry weight:398.0 kg (877.4 pounds)

Other specs

Comments:Windshield. Infotainment. USB. Bluetooth.
Carrying capacity:Saddle bags, top box
Light:High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, 6-speed, low fuel warning, ABS
Instruments:Large speedometer and tachometer with wide numbers; large fuel and volt gauges with wide numbers; display features odometer, trip A, trip B, range to empty, and gear indicator; and larger telltale indicators
Starter:Electric
Color options:Vivid Black, Twisted Cherry, Silver Fortune/Black Tempest, Silver Fortune/Sumatra Brown, Olive Gold/Black Tempest, Wicked Red/Twisted Cherry, Legend Blue/Vivid Black
