Harley-Davidson Softail Herritage Classic - 2018 Specifications and Reviews

2018
Not Rated stars Average rating: Not Rated from 0 votes
.

General information

Category:Custom / cruiser
Year:2018
Model:Harley-Davidson Softail Herritage Classic

Engine and Transmission Specifications

Exhaust system:2-into-2 shorty dual; catalyst in muffler
Greenhouse gases:127.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel consumption:5.50 litres/100 km (18.2 km/l or 42.77 mpg)
Driveline:Primary chain, 34/46 ratio
Clutch:Multi-plate with diaphragm spring in oil bath
Transmission type,final drive:Belt
Gearbox:6-speed
Cooling system:Air
Fuel control:Double Overhead Cams/Twin Cam (DOHC)
Fuel system:Injection. Electronic Sequential Port Fuel Injection
Bore x Stroke:98.4 x 111.1 mm (3.9 x 4.4 inches)
Compression:9.7:1
Torque:145.00 Nm (14.8 kgf-m or 107.0 ft.lbs) @ 3000 Revolutions">RPM
Power:86.00 Horsepower">HP (62.8 Kilowatt">kW)) @ 5020 Revolutions">RPM
Engine details:Milwaukee-Eight® 107, Optional Milwaukee-Eight® 114 Big Twin
Engine type:V2, four-stroke


Brakes, suspension, Frame and wheels

Wheels:Gloss Black, Steel Laced
Rear brakes:Single disc. ABS. 2-piston
Front brakes:Single disc. ABS. 4-piston
Rear tyre:150/80-B16
Front tyre:130/90-B16
Rear Suspension:Twin shocks
Front Suspension:Telescopic fork
Trail:145 mm (5.7 inches)
Rake (fork angle):30.0°

Physical measures and capacities

Oil capacity:4.70 litres (0.31 quarts)
Fuel capacity:18.90 litres (4.99 gallons)
Wheelbase:1,630 mm (64.2 inches)
Ground clearance:120 mm (4.7 inches)
Overall length:2,415 mm (95.1 inches)
Seat height:680 mm (26.8 inches) If adjustable, lowest setting.
Power/weight ratio:0.2722 HP/kg
Weight incl. oil, gas, etc:330.0 kg (727.5 pounds)
Dry weight:316.0 kg (696.7 pounds)

Other specs

Light:High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings
Instruments:Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
Starter:Electric
Color options:Vivid Black, Twisted Cherry, Silver Fortune, Olive Gold/Black Tempest, Industrial Gray Denim/Black Denim, Red Iron Denim, Legend Blue/Vivid Black
